声明：该文章代码是在正点原子教学下写出的LCD驱动代码上进行了修改能兼容更多字号( ˘ ³˘)❤️
如有侵权，请私信联系删除
文章目录
- 前言
- 代码
- lcd.c
- lcd.h
- font.h
前言
由于TFTLCD4.3寸屏幕太大了，正点原子的代码只能显示12/16/24字号的字符或者汉字觉得太小了，所以便决定改一下代码，通过font.h移入3232和6464字号的ASCII字符集，修改能接受字库更广的LCD_ShowChar字符显示函数，加入LCD_ShowChinese能显示任意大小字符或者汉字的函数（宏定义range限制范围，默认为8~64），使用方法:在取字模软件中取字模，其配置要求与下面完全一致，然后将取出的字模移入font.h对应数组中，剩下的就是调用函数了，**加字库的话按下面要求将字符集进行取模后也移到font.h里面去就可以了，加入字库或者更多大小自摸后，要将新的自摸数组或者字库数组按照下面格式写到下面函数中
//ASCII字符集: !"#$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcdefghijklmnopqrstuvwxyz{|}~
//PC2LCD2002取模方式设置：阴码+逐列式+顺向+C51格式
u8 Disguise_ChineseSize(u8 size,u8 num,u32 t)
{u8 tempx;if(size==8) tempx= chinese_one_88[num][t];if(size==9) tempx= chinese_one_99[num][t];if(size==10) tempx= chinese_one_1010[num][t];if(size==11) tempx= chinese_one_1111[num][t];if(size==12) tempx= chinese_one_1212[num][t];if(size==13) tempx= chinese_one_1313[num][t];if(size==14) tempx= chinese_one_1414[num][t];if(size==15) tempx= chinese_one_1515[num][t];if(size==16) tempx= chinese_one_1616[num][t];if(size==17) tempx= chinese_one_1717[num][t];if(size==18) tempx= chinese_one_1818[num][t];if(size==19) tempx= chinese_one_1919[num][t];if(size==20) tempx= chinese_one_2020[num][t];if(size==21) tempx= chinese_one_2121[num][t];if(size==22) tempx= chinese_one_2222[num][t];if(size==23) tempx= chinese_one_2323[num][t];if(size==24) tempx= chinese_one_2424[num][t];if(size==25) tempx= chinese_one_2525[num][t];if(size==26) tempx= chinese_one_2626[num][t];if(size==27) tempx= chinese_one_2727[num][t];if(size==28) tempx= chinese_one_2828[num][t];if(size==29) tempx= chinese_one_2929[num][t];if(size==30) tempx= chinese_one_3030[num][t];if(size==31) tempx= chinese_one_3131[num][t];if(size==32) tempx= chinese_one_3232[num][t];if(size==64) tempx= chinese_one_6464[num][t];return tempx;
}u8 Disguise_CharSize(u8 size,u8 num,u32 t)
{u8 tempx;if(size==12)tempx=asc2_1206[num][t]; //调用1206字体if(size==16)tempx=asc2_1608[num][t]; //调用1608字体if(size==24)tempx=asc2_2412[num][t]; //调用2412字体if(size==32)tempx=asc3232[num][t]; //32if(size==64)tempx=asc6464[num][t]; //64return tempx;
}
代码
lcd.c
#include "lcd.h"
#include "stdlib.h"
#include "font.h"
#include "usart.h"
#include "delay.h"
//
//STM32F103ZE核心板
//2.4寸/2.8寸/3.5寸/4.3寸/7寸 TFT液晶驱动
//支持驱动IC型号包括:ILI9341/ILI9325/RM68042/RM68021/ILI9320/ILI9328/LGDP4531/LGDP4535/
// SPFD5408/1505/B505/C505/NT35310/NT35510/SSD1963等 // //range为目前size的范围
#define range 64//LCD的画笔颜色和背景色
u16 POINT_COLOR=0x0000; //画笔颜色
u16 BACK_COLOR=0xFFFF; //背景色 //管理LCD重要参数
//默认为竖屏
_lcd_dev lcddev;//写寄存器函数
//regval:寄存器值
void LCD_WR_REG(u16 regval)
{ LCD->LCD_REG=regval;//写入要写的寄存器序号
}
//写LCD数据
//data:要写入的值
void LCD_WR_DATA(u16 data)
{ LCD->LCD_RAM=data;
}
//读LCD数据
//返回值:读到的值
u16 LCD_RD_DATA(void)
{vu16 ram; //防止被优化ram=LCD->LCD_RAM; return ram;
}
//写寄存器
//LCD_Reg:寄存器地址
//LCD_RegValue:要写入的数据
void LCD_WriteReg(u16 LCD_Reg,u16 LCD_RegValue)
{ LCD->LCD_REG = LCD_Reg; //写入要写的寄存器序号 LCD->LCD_RAM = LCD_RegValue;//写入数据
}
//读寄存器
//LCD_Reg:寄存器地址
//返回值:读到的数据
u16 LCD_ReadReg(u16 LCD_Reg)
{ LCD_WR_REG(LCD_Reg); //写入要读的寄存器序号delay_us(5); return LCD_RD_DATA(); //返回读到的值
}
//开始写GRAM
void LCD_WriteRAM_Prepare(void)
{LCD->LCD_REG=lcddev.wramcmd;
}
//LCD写GRAM
//RGB_Code:颜色值
void LCD_WriteRAM(u16 RGB_Code)
{ LCD->LCD_RAM = RGB_Code;//写十六位GRAM
}
//从ILI93xx读出的数据为GBR格式，而我们写入的时候为RGB格式。
//通过该函数转换
//c:GBR格式的颜色值
//返回值：RGB格式的颜色值
u16 LCD_BGR2RGB(u16 c)
{u16 r,g,b,rgb; b=(c>>0)&0x1f;g=(c>>5)&0x3f;r=(c>>11)&0x1f; rgb=(b<<11)+(g<<5)+(r<<0); return(rgb);
}
//当mdk -O1时间优化时需要设置
//延时i
void opt_delay(u8 i)
{while(i--);
}
//读取个某点的颜色值
//x,y:坐标
//返回值:此点的颜色
u16 LCD_ReadPoint(u16 x,u16 y)
{u16 r=0,g=0,b=0;if(x>=lcddev.width||y>=lcddev.height)return 0; //超过了范围,直接返回 LCD_SetCursor(x,y); if(lcddev.id==0X9341||lcddev.id==0X6804||lcddev.id==0X5310||lcddev.id==0X1963)LCD_WR_REG(0X2E);//9341/6804/3510/1963 发送读GRAM指令else if(lcddev.id==0X5510)LCD_WR_REG(0X2E00); //5510 发送读GRAM指令else LCD_WR_REG(0X22); //其他IC发送读GRAM指令if(lcddev.id==0X9320)opt_delay(2); //FOR 9320,延时2us r=LCD_RD_DATA(); //dummy Read if(lcddev.id==0X1963)return r; //1963直接读就可以 opt_delay(2); r=LCD_RD_DATA(); //实际坐标颜色if(lcddev.id==0X9341||lcddev.id==0X5310||lcddev.id==0X5510) //9341/NT35310/NT35510要分2次读出{opt_delay(2); b=LCD_RD_DATA(); g=r&0XFF; //对于9341/5310/5510,第一次读取的是RG的值,R在前,G在后,各占8位g<<=8;} if(lcddev.id==0X9325||lcddev.id==0X4535||lcddev.id==0X4531||lcddev.id==0XB505||lcddev.id==0XC505)return r; //这几种IC直接返回颜色值else if(lcddev.id==0X9341||lcddev.id==0X5310||lcddev.id==0X5510)return (((r>>11)<<11)|((g>>10)<<5)|(b>>11));//ILI9341/NT35310/NT35510需要公式转换一下else return LCD_BGR2RGB(r); //其他IC
}
//LCD开启显示
void LCD_DisplayOn(void)
{ if(lcddev.id==0X9341||lcddev.id==0X6804||lcddev.id==0X5310||lcddev.id==0X1963)LCD_WR_REG(0X29); //开启显示else if(lcddev.id==0X5510)LCD_WR_REG(0X2900); //开启显示else LCD_WriteReg(0X07,0x0173); //开启显示
}
//LCD关闭显示
void LCD_DisplayOff(void)
{ if(lcddev.id==0X9341||lcddev.id==0X6804||lcddev.id==0X5310||lcddev.id==0X1963)LCD_WR_REG(0X28); //关闭显示else if(lcddev.id==0X5510)LCD_WR_REG(0X2800); //关闭显示else LCD_WriteReg(0X07,0x0);//关闭显示
}
//设置光标位置
//Xpos:横坐标
//Ypos:纵坐标
void LCD_SetCursor(u16 Xpos, u16 Ypos)
{ if(lcddev.id==0X9341||lcddev.id==0X5310){ LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(Xpos>>8);LCD_WR_DATA(Xpos&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(Ypos>>8);LCD_WR_DATA(Ypos&0XFF); }else if(lcddev.id==0X6804){if(lcddev.dir==1)Xpos=lcddev.width-1-Xpos;//横屏时处理LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(Xpos>>8);LCD_WR_DATA(Xpos&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(Ypos>>8);LCD_WR_DATA(Ypos&0XFF); }else if(lcddev.id==0X1963){ if(lcddev.dir==0)//x坐标需要变换{Xpos=lcddev.width-1-Xpos;LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(0);LCD_WR_DATA(0); LCD_WR_DATA(Xpos>>8);LCD_WR_DATA(Xpos&0XFF); }else{LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(Xpos>>8);LCD_WR_DATA(Xpos&0XFF); LCD_WR_DATA((lcddev.width-1)>>8);LCD_WR_DATA((lcddev.width-1)&0XFF); } LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(Ypos>>8);LCD_WR_DATA(Ypos&0XFF); LCD_WR_DATA((lcddev.height-1)>>8);LCD_WR_DATA((lcddev.height-1)&0XFF); }else if(lcddev.id==0X5510){LCD_WR_REG(lcddev.setxcmd);LCD_WR_DATA(Xpos>>8); LCD_WR_REG(lcddev.setxcmd+1);LCD_WR_DATA(Xpos&0XFF); LCD_WR_REG(lcddev.setycmd);LCD_WR_DATA(Ypos>>8); LCD_WR_REG(lcddev.setycmd+1);LCD_WR_DATA(Ypos&0XFF); }else{if(lcddev.dir==1)Xpos=lcddev.width-1-Xpos;//横屏其实就是调转x,y坐标LCD_WriteReg(lcddev.setxcmd, Xpos);LCD_WriteReg(lcddev.setycmd, Ypos);}
}
//设置LCD的自动扫描方向
//注意:其他函数可能会受到此函数设置的影响(尤其是9341/6804这两个奇葩),
//所以,一般设置为L2R_U2D即可,如果设置为其他扫描方式,可能导致显示不正常.
//dir:0~7,代表8个方向(具体定义见lcd.h)
//9320/9325/9328/4531/4535/1505/b505/5408/9341/5310/5510/1963等IC已经实际测试
void LCD_Scan_Dir(u8 dir)
{u16 regval=0;u16 dirreg=0;u16 temp; if((lcddev.dir==1&&lcddev.id!=0X6804&&lcddev.id!=0X1963)||(lcddev.dir==0&&lcddev.id==0X1963))//横屏时，对6804和1963不改变扫描方向！竖屏时1963改变方向{ switch(dir)//方向转换{case 0:dir=6;break;case 1:dir=7;break;case 2:dir=4;break;case 3:dir=5;break;case 4:dir=1;break;case 5:dir=0;break;case 6:dir=3;break;case 7:dir=2;break; }} if(lcddev.id==0x9341||lcddev.id==0X6804||lcddev.id==0X5310||lcddev.id==0X5510||lcddev.id==0X1963)//9341/6804/5310/5510/1963,特殊处理{switch(dir){case L2R_U2D://从左到右,从上到下regval|=(0<<7)|(0<<6)|(0<<5); break;case L2R_D2U://从左到右,从下到上regval|=(1<<7)|(0<<6)|(0<<5); break;case R2L_U2D://从右到左,从上到下regval|=(0<<7)|(1<<6)|(0<<5); break;case R2L_D2U://从右到左,从下到上regval|=(1<<7)|(1<<6)|(0<<5); break; case U2D_L2R://从上到下,从左到右regval|=(0<<7)|(0<<6)|(1<<5); break;case U2D_R2L://从上到下,从右到左regval|=(0<<7)|(1<<6)|(1<<5); break;case D2U_L2R://从下到上,从左到右regval|=(1<<7)|(0<<6)|(1<<5); break;case D2U_R2L://从下到上,从右到左regval|=(1<<7)|(1<<6)|(1<<5); break; }if(lcddev.id==0X5510)dirreg=0X3600;else dirreg=0X36;if((lcddev.id!=0X5310)&&(lcddev.id!=0X5510)&&(lcddev.id!=0X1963))regval|=0X08;//5310/5510/1963不需要BGR if(lcddev.id==0X6804)regval|=0x02;//6804的BIT6和9341的反了 LCD_WriteReg(dirreg,regval);if(lcddev.id!=0X1963)//1963不做坐标处理{if(regval&0X20){if(lcddev.width<lcddev.height)//交换X,Y{temp=lcddev.width;lcddev.width=lcddev.height;lcddev.height=temp;}}else {if(lcddev.width>lcddev.height)//交换X,Y{temp=lcddev.width;lcddev.width=lcddev.height;lcddev.height=temp;}} }if(lcddev.id==0X5510){LCD_WR_REG(lcddev.setxcmd);LCD_WR_DATA(0); LCD_WR_REG(lcddev.setxcmd+1);LCD_WR_DATA(0); LCD_WR_REG(lcddev.setxcmd+2);LCD_WR_DATA((lcddev.width-1)>>8); LCD_WR_REG(lcddev.setxcmd+3);LCD_WR_DATA((lcddev.width-1)&0XFF); LCD_WR_REG(lcddev.setycmd);LCD_WR_DATA(0); LCD_WR_REG(lcddev.setycmd+1);LCD_WR_DATA(0); LCD_WR_REG(lcddev.setycmd+2);LCD_WR_DATA((lcddev.height-1)>>8); LCD_WR_REG(lcddev.setycmd+3);LCD_WR_DATA((lcddev.height-1)&0XFF);}else{LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(0);LCD_WR_DATA(0);LCD_WR_DATA((lcddev.width-1)>>8);LCD_WR_DATA((lcddev.width-1)&0XFF);LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(0);LCD_WR_DATA(0);LCD_WR_DATA((lcddev.height-1)>>8);LCD_WR_DATA((lcddev.height-1)&0XFF); }}else {switch(dir){case L2R_U2D://从左到右,从上到下regval|=(1<<5)|(1<<4)|(0<<3); break;case L2R_D2U://从左到右,从下到上regval|=(0<<5)|(1<<4)|(0<<3); break;case R2L_U2D://从右到左,从上到下regval|=(1<<5)|(0<<4)|(0<<3);break;case R2L_D2U://从右到左,从下到上regval|=(0<<5)|(0<<4)|(0<<3); break; case U2D_L2R://从上到下,从左到右regval|=(1<<5)|(1<<4)|(1<<3); break;case U2D_R2L://从上到下,从右到左regval|=(1<<5)|(0<<4)|(1<<3); break;case D2U_L2R://从下到上,从左到右regval|=(0<<5)|(1<<4)|(1<<3); break;case D2U_R2L://从下到上,从右到左regval|=(0<<5)|(0<<4)|(1<<3); break; } dirreg=0X03;regval|=1<<12; LCD_WriteReg(dirreg,regval);}
}
//画点
//x,y:坐标
//POINT_COLOR:此点的颜色
void LCD_DrawPoint(u16 x,u16 y)
{LCD_SetCursor(x,y); //设置光标位置 LCD_WriteRAM_Prepare(); //开始写入GRAMLCD->LCD_RAM=POINT_COLOR;
}
//快速画点
//x,y:坐标
//color:颜色
void LCD_Fast_DrawPoint(u16 x,u16 y,u16 color)
{ if(lcddev.id==0X9341||lcddev.id==0X5310){LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(x>>8);LCD_WR_DATA(x&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(y>>8);LCD_WR_DATA(y&0XFF); }else if(lcddev.id==0X5510){LCD_WR_REG(lcddev.setxcmd);LCD_WR_DATA(x>>8); LCD_WR_REG(lcddev.setxcmd+1);LCD_WR_DATA(x&0XFF); LCD_WR_REG(lcddev.setycmd);LCD_WR_DATA(y>>8); LCD_WR_REG(lcddev.setycmd+1);LCD_WR_DATA(y&0XFF); }else if(lcddev.id==0X1963){if(lcddev.dir==0)x=lcddev.width-1-x;LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(x>>8);LCD_WR_DATA(x&0XFF); LCD_WR_DATA(x>>8);LCD_WR_DATA(x&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(y>>8);LCD_WR_DATA(y&0XFF); LCD_WR_DATA(y>>8);LCD_WR_DATA(y&0XFF); }else if(lcddev.id==0X6804){ if(lcddev.dir==1)x=lcddev.width-1-x;//横屏时处理LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(x>>8);LCD_WR_DATA(x&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(y>>8);LCD_WR_DATA(y&0XFF); }else{if(lcddev.dir==1)x=lcddev.width-1-x;//横屏其实就是调转x,y坐标LCD_WriteReg(lcddev.setxcmd,x);LCD_WriteReg(lcddev.setycmd,y);} LCD->LCD_REG=lcddev.wramcmd; LCD->LCD_RAM=color;
}
//SSD1963 背光设置
//pwm:背光等级,0~100.越大越亮.
void LCD_SSD_BackLightSet(u8 pwm)
{ LCD_WR_REG(0xBE); //配置PWM输出LCD_WR_DATA(0x05); //1设置PWM频率LCD_WR_DATA(pwm*2.55);//2设置PWM占空比LCD_WR_DATA(0x01); //3设置CLCD_WR_DATA(0xFF); //4设置DLCD_WR_DATA(0x00); //5设置ELCD_WR_DATA(0x00); //6设置F
}//设置LCD显示方向
//dir:0,竖屏；1,横屏
void LCD_Display_Dir(u8 dir)
{if(dir==0) //竖屏{lcddev.dir=0; //竖屏lcddev.width=240;lcddev.height=320;if(lcddev.id==0X9341||lcddev.id==0X6804||lcddev.id==0X5310){lcddev.wramcmd=0X2C;lcddev.setxcmd=0X2A;lcddev.setycmd=0X2B; if(lcddev.id==0X6804||lcddev.id==0X5310){lcddev.width=320;lcddev.height=480;}}else if(lcddev.id==0x5510){lcddev.wramcmd=0X2C00;lcddev.setxcmd=0X2A00;lcddev.setycmd=0X2B00; lcddev.width=480;lcddev.height=800;}else if(lcddev.id==0X1963){lcddev.wramcmd=0X2C; //设置写入GRAM的指令 lcddev.setxcmd=0X2B; //设置写X坐标指令lcddev.setycmd=0X2A; //设置写Y坐标指令lcddev.width=480; //设置宽度480lcddev.height=800; //设置高度800 }else{lcddev.wramcmd=0X22;lcddev.setxcmd=0X20;lcddev.setycmd=0X21; }}else //横屏{ lcddev.dir=1; //横屏lcddev.width=320;lcddev.height=240;if(lcddev.id==0X9341||lcddev.id==0X5310){lcddev.wramcmd=0X2C;lcddev.setxcmd=0X2A;lcddev.setycmd=0X2B; }else if(lcddev.id==0X6804) {lcddev.wramcmd=0X2C;lcddev.setxcmd=0X2B;lcddev.setycmd=0X2A; }else if(lcddev.id==0x5510){lcddev.wramcmd=0X2C00;lcddev.setxcmd=0X2A00;lcddev.setycmd=0X2B00; lcddev.width=800;lcddev.height=480;}else if(lcddev.id==0X1963){lcddev.wramcmd=0X2C; //设置写入GRAM的指令 lcddev.setxcmd=0X2A; //设置写X坐标指令lcddev.setycmd=0X2B; //设置写Y坐标指令lcddev.width=800; //设置宽度800lcddev.height=480; //设置高度480 }else{lcddev.wramcmd=0X22;lcddev.setxcmd=0X21;lcddev.setycmd=0X20; }if(lcddev.id==0X6804||lcddev.id==0X5310){ lcddev.width=480;lcddev.height=320; }} LCD_Scan_Dir(DFT_SCAN_DIR); //默认扫描方向
}
//设置窗口,并自动设置画点坐标到窗口左上角(sx,sy).
//sx,sy:窗口起始坐标(左上角)
//width,height:窗口宽度和高度,必须大于0!!
//窗体大小:width*height.
void LCD_Set_Window(u16 sx,u16 sy,u16 width,u16 height)
{ u8 hsareg,heareg,vsareg,veareg;u16 hsaval,heaval,vsaval,veaval; u16 twidth,theight;twidth=sx+width-1;theight=sy+height-1;if(lcddev.id==0X9341||lcddev.id==0X5310||lcddev.id==0X6804||(lcddev.dir==1&&lcddev.id==0X1963)){LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(sx>>8); LCD_WR_DATA(sx&0XFF); LCD_WR_DATA(twidth>>8); LCD_WR_DATA(twidth&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(sy>>8); LCD_WR_DATA(sy&0XFF); LCD_WR_DATA(theight>>8); LCD_WR_DATA(theight&0XFF); }else if(lcddev.id==0X1963)//1963竖屏特殊处理{sx=lcddev.width-width-sx; height=sy+height-1; LCD_WR_REG(lcddev.setxcmd); LCD_WR_DATA(sx>>8); LCD_WR_DATA(sx&0XFF); LCD_WR_DATA((sx+width-1)>>8); LCD_WR_DATA((sx+width-1)&0XFF); LCD_WR_REG(lcddev.setycmd); LCD_WR_DATA(sy>>8); LCD_WR_DATA(sy&0XFF); LCD_WR_DATA(height>>8); LCD_WR_DATA(height&0XFF); }else if(lcddev.id==0X5510){LCD_WR_REG(lcddev.setxcmd);LCD_WR_DATA(sx>>8); LCD_WR_REG(lcddev.setxcmd+1);LCD_WR_DATA(sx&0XFF); LCD_WR_REG(lcddev.setxcmd+2);LCD_WR_DATA(twidth>>8); LCD_WR_REG(lcddev.setxcmd+3);LCD_WR_DATA(twidth&0XFF); LCD_WR_REG(lcddev.setycmd);LCD_WR_DATA(sy>>8); LCD_WR_REG(lcddev.setycmd+1);LCD_WR_DATA(sy&0XFF); LCD_WR_REG(lcddev.setycmd+2);LCD_WR_DATA(theight>>8); LCD_WR_REG(lcddev.setycmd+3);LCD_WR_DATA(theight&0XFF); }else //其他驱动IC{if(lcddev.dir==1)//横屏{//窗口值hsaval=sy; heaval=theight;vsaval=lcddev.width-twidth-1;veaval=lcddev.width-sx-1; }else{ hsaval=sx; heaval=twidth;vsaval=sy;veaval=theight;} hsareg=0X50;heareg=0X51;//水平方向窗口寄存器vsareg=0X52;veareg=0X53;//垂直方向窗口寄存器 //设置寄存器值LCD_WriteReg(hsareg,hsaval);LCD_WriteReg(heareg,heaval);LCD_WriteReg(vsareg,vsaval);LCD_WriteReg(veareg,veaval); LCD_SetCursor(sx,sy); //设置光标位置}
}
//初始化lcd
//该初始化函数可以初始化各种ILI93XX液晶,但是其他函数是基于ILI9320的!!!
//在其他型号的驱动芯片上没有测试!
void LCD_Init(void)
{ GPIO_InitTypeDef GPIO_InitStructure;FSMC_NORSRAMInitTypeDef FSMC_NORSRAMInitStructure;FSMC_NORSRAMTimingInitTypeDef readWriteTiming; FSMC_NORSRAMTimingInitTypeDef writeTiming;RCC_AHBPeriphClockCmd(RCC_AHBPeriph_FSMC,ENABLE); //使能FSMC时钟RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOB|RCC_APB2Periph_GPIOD|RCC_APB2Periph_GPIOE|RCC_APB2Periph_GPIOG,ENABLE);//使能PORTB,D,E,G以及AFIO复用功能时钟GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0; //PB0 推挽输出 背光GPIO_InitStructure.GPIO_Mode = GPIO_Mode_Out_PP; //推挽输出GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;GPIO_Init(GPIOB, &GPIO_InitStructure);//PORTD复用推挽输出 GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0|GPIO_Pin_1|GPIO_Pin_4|GPIO_Pin_5|GPIO_Pin_8|GPIO_Pin_9|GPIO_Pin_10|GPIO_Pin_14|GPIO_Pin_15; // //PORTD复用推挽输出 GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP; //复用推挽输出 GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;GPIO_Init(GPIOD, &GPIO_InitStructure); //PORTE复用推挽输出 GPIO_InitStructure.GPIO_Pin = GPIO_Pin_7|GPIO_Pin_8|GPIO_Pin_9|GPIO_Pin_10|GPIO_Pin_11|GPIO_Pin_12|GPIO_Pin_13|GPIO_Pin_14|GPIO_Pin_15; // //PORTD复用推挽输出 GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP; //复用推挽输出 GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;GPIO_Init(GPIOE, &GPIO_InitStructure); // //PORTG12复用推挽输出 A0 GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0|GPIO_Pin_12; // //PORTD复用推挽输出 GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP; //复用推挽输出 GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;GPIO_Init(GPIOG, &GPIO_InitStructure); readWriteTiming.FSMC_AddressSetupTime = 0x01; //地址建立时间（ADDSET）为2个HCLK 1/36M=27nsreadWriteTiming.FSMC_AddressHoldTime = 0x00; //地址保持时间（ADDHLD）模式A未用到 readWriteTiming.FSMC_DataSetupTime = 0x0f; // 数据保存时间为16个HCLK,因为液晶驱动IC的读数据的时候，速度不能太快，尤其对1289这个IC。readWriteTiming.FSMC_BusTurnAroundDuration = 0x00;readWriteTiming.FSMC_CLKDivision = 0x00;readWriteTiming.FSMC_DataLatency = 0x00;readWriteTiming.FSMC_AccessMode = FSMC_AccessMode_A; //模式A writeTiming.FSMC_AddressSetupTime = 0x00; //地址建立时间（ADDSET）为1个HCLK writeTiming.FSMC_AddressHoldTime = 0x00; //地址保持时间（A writeTiming.FSMC_DataSetupTime = 0x03; 数据保存时间为4个HCLK writeTiming.FSMC_BusTurnAroundDuration = 0x00;writeTiming.FSMC_CLKDivision = 0x00;writeTiming.FSMC_DataLatency = 0x00;writeTiming.FSMC_AccessMode = FSMC_AccessMode_A; //模式A FSMC_NORSRAMInitStructure.FSMC_Bank = FSMC_Bank1_NORSRAM4;// 这里我们使用NE4 ，也就对应BTCR[6],[7]。FSMC_NORSRAMInitStructure.FSMC_DataAddressMux = FSMC_DataAddressMux_Disable; // 不复用数据地址FSMC_NORSRAMInitStructure.FSMC_MemoryType =FSMC_MemoryType_SRAM;// FSMC_MemoryType_SRAM; //SRAM FSMC_NORSRAMInitStructure.FSMC_MemoryDataWidth = FSMC_MemoryDataWidth_16b;//存储器数据宽度为16bit FSMC_NORSRAMInitStructure.FSMC_BurstAccessMode =FSMC_BurstAccessMode_Disable;// FSMC_BurstAccessMode_Disable; FSMC_NORSRAMInitStructure.FSMC_WaitSignalPolarity = FSMC_WaitSignalPolarity_Low;FSMC_NORSRAMInitStructure.FSMC_AsynchronousWait=FSMC_AsynchronousWait_Disable; FSMC_NORSRAMInitStructure.FSMC_WrapMode = FSMC_WrapMode_Disable; FSMC_NORSRAMInitStructure.FSMC_WaitSignalActive = FSMC_WaitSignalActive_BeforeWaitState; FSMC_NORSRAMInitStructure.FSMC_WriteOperation = FSMC_WriteOperation_Enable; // 存储器写使能FSMC_NORSRAMInitStructure.FSMC_WaitSignal = FSMC_WaitSignal_Disable; FSMC_NORSRAMInitStructure.FSMC_ExtendedMode = FSMC_ExtendedMode_Enable; // 读写使用不同的时序FSMC_NORSRAMInitStructure.FSMC_WriteBurst = FSMC_WriteBurst_Disable; FSMC_NORSRAMInitStructure.FSMC_ReadWriteTimingStruct = &readWriteTiming; //读写时序FSMC_NORSRAMInitStructure.FSMC_WriteTimingStruct = &writeTiming; //写时序FSMC_NORSRAMInit(&FSMC_NORSRAMInitStructure); //初始化FSMC配置FSMC_NORSRAMCmd(FSMC_Bank1_NORSRAM4, ENABLE); // 使能BANK1 delay_ms(50); // delay 50 ms lcddev.id=LCD_ReadReg(0x0000); //读ID（9320/9325/9328/4531/4535等IC） if(lcddev.id<0XFF||lcddev.id==0XFFFF||lcddev.id==0X9300)//读到ID不正确,新增lcddev.id==0X9300判断，因为9341在未被复位的情况下会被读成9300{ //尝试9341 ID的读取 LCD_WR_REG(0XD3); lcddev.id=LCD_RD_DATA(); //dummy read lcddev.id=LCD_RD_DATA(); //读到0X00lcddev.id=LCD_RD_DATA(); //读取93 lcddev.id<<=8;lcddev.id|=LCD_RD_DATA(); //读取41 if(lcddev.id!=0X9341) //非9341,尝试是不是6804{ LCD_WR_REG(0XBF); lcddev.id=LCD_RD_DATA(); //dummy read lcddev.id=LCD_RD_DATA(); //读回0X01 lcddev.id=LCD_RD_DATA(); //读回0XD0 lcddev.id=LCD_RD_DATA(); //这里读回0X68 lcddev.id<<=8;lcddev.id|=LCD_RD_DATA(); //这里读回0X04 if(lcddev.id!=0X6804) //也不是6804,尝试看看是不是NT35310{ LCD_WR_REG(0XD4); lcddev.id=LCD_RD_DATA();//dummy read lcddev.id=LCD_RD_DATA();//读回0X01 lcddev.id=LCD_RD_DATA();//读回0X53 lcddev.id<<=8; lcddev.id|=LCD_RD_DATA(); //这里读回0X10 if(lcddev.id!=0X5310) //也不是NT35310,尝试看看是不是NT35510{LCD_WR_REG(0XDA00); lcddev.id=LCD_RD_DATA(); //读回0X00 LCD_WR_REG(0XDB00); lcddev.id=LCD_RD_DATA(); //读回0X80lcddev.id<<=8; LCD_WR_REG(0XDC00); lcddev.id|=LCD_RD_DATA(); //读回0X00 if(lcddev.id==0x8000)lcddev.id=0x5510;//NT35510读回的ID是8000H,为方便区分,我们强制设置为5510if(lcddev.id!=0X5510) //也不是NT5510,尝试看看是不是SSD1963{LCD_WR_REG(0XA1);lcddev.id=LCD_RD_DATA();lcddev.id=LCD_RD_DATA(); //读回0X57lcddev.id<<=8; lcddev.id|=LCD_RD_DATA(); //读回0X61 if(lcddev.id==0X5761)lcddev.id=0X1963;//SSD1963读回的ID是5761H,为方便区分,我们强制设置为1963}}}} } printf(" LCD ID:%x\r\n",lcddev.id); //打印LCD ID if(lcddev.id==0X9341) //9341初始化{ LCD_WR_REG(0xCF); LCD_WR_DATA(0x00); LCD_WR_DATA(0xC1); LCD_WR_DATA(0X30); LCD_WR_REG(0xED); LCD_WR_DATA(0x64); LCD_WR_DATA(0x03); LCD_WR_DATA(0X12); LCD_WR_DATA(0X81); LCD_WR_REG(0xE8); LCD_WR_DATA(0x85); LCD_WR_DATA(0x10); LCD_WR_DATA(0x7A); LCD_WR_REG(0xCB); LCD_WR_DATA(0x39); LCD_WR_DATA(0x2C); LCD_WR_DATA(0x00); LCD_WR_DATA(0x34); LCD_WR_DATA(0x02); LCD_WR_REG(0xF7); LCD_WR_DATA(0x20); LCD_WR_REG(0xEA); LCD_WR_DATA(0x00); LCD_WR_DATA(0x00); LCD_WR_REG(0xC0); //Power control LCD_WR_DATA(0x1B); //VRH[5:0] LCD_WR_REG(0xC1); //Power control LCD_WR_DATA(0x01); //SAP[2:0];BT[3:0] LCD_WR_REG(0xC5); //VCM control LCD_WR_DATA(0x30); //3FLCD_WR_DATA(0x30); //3CLCD_WR_REG(0xC7); //VCM control2 LCD_WR_DATA(0XB7); LCD_WR_REG(0x36); // Memory Access Control LCD_WR_DATA(0x48); LCD_WR_REG(0x3A); LCD_WR_DATA(0x55); LCD_WR_REG(0xB1); LCD_WR_DATA(0x00); LCD_WR_DATA(0x1A); LCD_WR_REG(0xB6); // Display Function Control LCD_WR_DATA(0x0A); LCD_WR_DATA(0xA2); LCD_WR_REG(0xF2); // 3Gamma Function Disable LCD_WR_DATA(0x00); LCD_WR_REG(0x26); //Gamma curve selected LCD_WR_DATA(0x01); LCD_WR_REG(0xE0); //Set Gamma LCD_WR_DATA(0x0F); LCD_WR_DATA(0x2A); LCD_WR_DATA(0x28); LCD_WR_DATA(0x08); LCD_WR_DATA(0x0E); LCD_WR_DATA(0x08); LCD_WR_DATA(0x54); LCD_WR_DATA(0XA9); LCD_WR_DATA(0x43); LCD_WR_DATA(0x0A); LCD_WR_DATA(0x0F); LCD_WR_DATA(0x00); LCD_WR_DATA(0x00); LCD_WR_DATA(0x00); LCD_WR_DATA(0x00); LCD_WR_REG(0XE1); //Set Gamma LCD_WR_DATA(0x00); LCD_WR_DATA(0x15); LCD_WR_DATA(0x17); LCD_WR_DATA(0x07); LCD_WR_DATA(0x11); LCD_WR_DATA(0x06); LCD_WR_DATA(0x2B); LCD_WR_DATA(0x56); LCD_WR_DATA(0x3C); LCD_WR_DATA(0x05); LCD_WR_DATA(0x10); LCD_WR_DATA(0x0F); LCD_WR_DATA(0x3F); LCD_WR_DATA(0x3F); LCD_WR_DATA(0x0F); LCD_WR_REG(0x2B); LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x01);LCD_WR_DATA(0x3f);LCD_WR_REG(0x2A); LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0xef); LCD_WR_REG(0x11); //Exit Sleepdelay_ms(120);LCD_WR_REG(0x29); //display on }else if(lcddev.id==0x6804) //6804初始化{LCD_WR_REG(0X11);delay_ms(20);LCD_WR_REG(0XD0);//VCI1 VCL VGH VGL DDVDH VREG1OUT power amplitude settingLCD_WR_DATA(0X07); LCD_WR_DATA(0X42); LCD_WR_DATA(0X1D); LCD_WR_REG(0XD1);//VCOMH VCOM_AC amplitude settingLCD_WR_DATA(0X00);LCD_WR_DATA(0X1a);LCD_WR_DATA(0X09); LCD_WR_REG(0XD2);//Operational Amplifier Circuit Constant Current Adjust , charge pump frequency settingLCD_WR_DATA(0X01);LCD_WR_DATA(0X22);LCD_WR_REG(0XC0);//REV SM GS LCD_WR_DATA(0X10);LCD_WR_DATA(0X3B);LCD_WR_DATA(0X00);LCD_WR_DATA(0X02);LCD_WR_DATA(0X11);LCD_WR_REG(0XC5);// Frame rate setting = 72HZ when setting 0x03LCD_WR_DATA(0X03);LCD_WR_REG(0XC8);//Gamma settingLCD_WR_DATA(0X00);LCD_WR_DATA(0X25);LCD_WR_DATA(0X21);LCD_WR_DATA(0X05);LCD_WR_DATA(0X00);LCD_WR_DATA(0X0a);LCD_WR_DATA(0X65);LCD_WR_DATA(0X25);LCD_WR_DATA(0X77);LCD_WR_DATA(0X50);LCD_WR_DATA(0X0f);LCD_WR_DATA(0X00); LCD_WR_REG(0XF8);LCD_WR_DATA(0X01); LCD_WR_REG(0XFE);LCD_WR_DATA(0X00);LCD_WR_DATA(0X02);LCD_WR_REG(0X20);//Exit invert modeLCD_WR_REG(0X36);LCD_WR_DATA(0X08);//原来是aLCD_WR_REG(0X3A);LCD_WR_DATA(0X55);//16位模式 LCD_WR_REG(0X2B);LCD_WR_DATA(0X00);LCD_WR_DATA(0X00);LCD_WR_DATA(0X01);LCD_WR_DATA(0X3F);LCD_WR_REG(0X2A);LCD_WR_DATA(0X00);LCD_WR_DATA(0X00);LCD_WR_DATA(0X01);LCD_WR_DATA(0XDF);delay_ms(120);LCD_WR_REG(0X29); }else if(lcddev.id==0x5310){ LCD_WR_REG(0xED);LCD_WR_DATA(0x01);LCD_WR_DATA(0xFE);LCD_WR_REG(0xEE);LCD_WR_DATA(0xDE);LCD_WR_DATA(0x21);LCD_WR_REG(0xF1);LCD_WR_DATA(0x01);LCD_WR_REG(0xDF);LCD_WR_DATA(0x10);//VCOMvoltage//LCD_WR_REG(0xC4);LCD_WR_DATA(0x8F); //5fLCD_WR_REG(0xC6);LCD_WR_DATA(0x00);LCD_WR_DATA(0xE2);LCD_WR_DATA(0xE2);LCD_WR_DATA(0xE2);LCD_WR_REG(0xBF);LCD_WR_DATA(0xAA);LCD_WR_REG(0xB0);LCD_WR_DATA(0x0D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x0D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x11);LCD_WR_DATA(0x00);LCD_WR_DATA(0x19);LCD_WR_DATA(0x00);LCD_WR_DATA(0x21);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x5D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x5D);LCD_WR_DATA(0x00);LCD_WR_REG(0xB1);LCD_WR_DATA(0x80);LCD_WR_DATA(0x00);LCD_WR_DATA(0x8B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x96);LCD_WR_DATA(0x00);LCD_WR_REG(0xB2);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x02);LCD_WR_DATA(0x00);LCD_WR_DATA(0x03);LCD_WR_DATA(0x00);LCD_WR_REG(0xB3);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xB4);LCD_WR_DATA(0x8B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x96);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA1);LCD_WR_DATA(0x00);LCD_WR_REG(0xB5);LCD_WR_DATA(0x02);LCD_WR_DATA(0x00);LCD_WR_DATA(0x03);LCD_WR_DATA(0x00);LCD_WR_DATA(0x04);LCD_WR_DATA(0x00);LCD_WR_REG(0xB6);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xB7);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3F);LCD_WR_DATA(0x00);LCD_WR_DATA(0x5E);LCD_WR_DATA(0x00);LCD_WR_DATA(0x64);LCD_WR_DATA(0x00);LCD_WR_DATA(0x8C);LCD_WR_DATA(0x00);LCD_WR_DATA(0xAC);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDC);LCD_WR_DATA(0x00);LCD_WR_DATA(0x70);LCD_WR_DATA(0x00);LCD_WR_DATA(0x90);LCD_WR_DATA(0x00);LCD_WR_DATA(0xEB);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDC);LCD_WR_DATA(0x00);LCD_WR_REG(0xB8);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xBA);LCD_WR_DATA(0x24);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xC1);LCD_WR_DATA(0x20);LCD_WR_DATA(0x00);LCD_WR_DATA(0x54);LCD_WR_DATA(0x00);LCD_WR_DATA(0xFF);LCD_WR_DATA(0x00);LCD_WR_REG(0xC2);LCD_WR_DATA(0x0A);LCD_WR_DATA(0x00);LCD_WR_DATA(0x04);LCD_WR_DATA(0x00);LCD_WR_REG(0xC3);LCD_WR_DATA(0x3C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3A);LCD_WR_DATA(0x00);LCD_WR_DATA(0x39);LCD_WR_DATA(0x00);LCD_WR_DATA(0x37);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x36);LCD_WR_DATA(0x00);LCD_WR_DATA(0x32);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2F);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x29);LCD_WR_DATA(0x00);LCD_WR_DATA(0x26);LCD_WR_DATA(0x00);LCD_WR_DATA(0x24);LCD_WR_DATA(0x00);LCD_WR_DATA(0x24);LCD_WR_DATA(0x00);LCD_WR_DATA(0x23);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x36);LCD_WR_DATA(0x00);LCD_WR_DATA(0x32);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2F);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x29);LCD_WR_DATA(0x00);LCD_WR_DATA(0x26);LCD_WR_DATA(0x00);LCD_WR_DATA(0x24);LCD_WR_DATA(0x00);LCD_WR_DATA(0x24);LCD_WR_DATA(0x00);LCD_WR_DATA(0x23);LCD_WR_DATA(0x00);LCD_WR_REG(0xC4);LCD_WR_DATA(0x62);LCD_WR_DATA(0x00);LCD_WR_DATA(0x05);LCD_WR_DATA(0x00);LCD_WR_DATA(0x84);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF0);LCD_WR_DATA(0x00);LCD_WR_DATA(0x18);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA4);LCD_WR_DATA(0x00);LCD_WR_DATA(0x18);LCD_WR_DATA(0x00);LCD_WR_DATA(0x50);LCD_WR_DATA(0x00);LCD_WR_DATA(0x0C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x17);LCD_WR_DATA(0x00);LCD_WR_DATA(0x95);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_DATA(0xE6);LCD_WR_DATA(0x00);LCD_WR_REG(0xC5);LCD_WR_DATA(0x32);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x65);LCD_WR_DATA(0x00);LCD_WR_DATA(0x76);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_REG(0xC6);LCD_WR_DATA(0x20);LCD_WR_DATA(0x00);LCD_WR_DATA(0x17);LCD_WR_DATA(0x00);LCD_WR_DATA(0x01);LCD_WR_DATA(0x00);LCD_WR_REG(0xC7);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xC8);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xC9);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xE0);LCD_WR_DATA(0x16);LCD_WR_DATA(0x00);LCD_WR_DATA(0x1C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x21);LCD_WR_DATA(0x00);LCD_WR_DATA(0x36);LCD_WR_DATA(0x00);LCD_WR_DATA(0x46);LCD_WR_DATA(0x00);LCD_WR_DATA(0x52);LCD_WR_DATA(0x00);LCD_WR_DATA(0x64);LCD_WR_DATA(0x00);LCD_WR_DATA(0x7A);LCD_WR_DATA(0x00);LCD_WR_DATA(0x8B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA8);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB9);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC4);LCD_WR_DATA(0x00);LCD_WR_DATA(0xCA);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD9);LCD_WR_DATA(0x00);LCD_WR_DATA(0xE0);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE1);LCD_WR_DATA(0x16);LCD_WR_DATA(0x00);LCD_WR_DATA(0x1C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x22);LCD_WR_DATA(0x00);LCD_WR_DATA(0x36);LCD_WR_DATA(0x00);LCD_WR_DATA(0x45);LCD_WR_DATA(0x00);LCD_WR_DATA(0x52);LCD_WR_DATA(0x00);LCD_WR_DATA(0x64);LCD_WR_DATA(0x00);LCD_WR_DATA(0x7A);LCD_WR_DATA(0x00);LCD_WR_DATA(0x8B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA8);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB9);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC4);LCD_WR_DATA(0x00);LCD_WR_DATA(0xCA);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD8);LCD_WR_DATA(0x00);LCD_WR_DATA(0xE0);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE2);LCD_WR_DATA(0x05);LCD_WR_DATA(0x00);LCD_WR_DATA(0x0B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x1B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x34);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x4F);LCD_WR_DATA(0x00);LCD_WR_DATA(0x61);LCD_WR_DATA(0x00);LCD_WR_DATA(0x79);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_DATA(0x97);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA6);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB7);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC7);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD1);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD6);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDD);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE3);LCD_WR_DATA(0x05);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA);LCD_WR_DATA(0x00);LCD_WR_DATA(0x1C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x33);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x50);LCD_WR_DATA(0x00);LCD_WR_DATA(0x62);LCD_WR_DATA(0x00);LCD_WR_DATA(0x78);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_DATA(0x97);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA6);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB7);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC7);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD1);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD5);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDD);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE4);LCD_WR_DATA(0x01);LCD_WR_DATA(0x00);LCD_WR_DATA(0x01);LCD_WR_DATA(0x00);LCD_WR_DATA(0x02);LCD_WR_DATA(0x00);LCD_WR_DATA(0x2A);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x4B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x5D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x74);LCD_WR_DATA(0x00);LCD_WR_DATA(0x84);LCD_WR_DATA(0x00);LCD_WR_DATA(0x93);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB3);LCD_WR_DATA(0x00);LCD_WR_DATA(0xBE);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC4);LCD_WR_DATA(0x00);LCD_WR_DATA(0xCD);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD3);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDD);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE5);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x02);LCD_WR_DATA(0x00);LCD_WR_DATA(0x29);LCD_WR_DATA(0x00);LCD_WR_DATA(0x3C);LCD_WR_DATA(0x00);LCD_WR_DATA(0x4B);LCD_WR_DATA(0x00);LCD_WR_DATA(0x5D);LCD_WR_DATA(0x00);LCD_WR_DATA(0x74);LCD_WR_DATA(0x00);LCD_WR_DATA(0x84);LCD_WR_DATA(0x00);LCD_WR_DATA(0x93);LCD_WR_DATA(0x00);LCD_WR_DATA(0xA2);LCD_WR_DATA(0x00);LCD_WR_DATA(0xB3);LCD_WR_DATA(0x00);LCD_WR_DATA(0xBE);LCD_WR_DATA(0x00);LCD_WR_DATA(0xC4);LCD_WR_DATA(0x00);LCD_WR_DATA(0xCD);LCD_WR_DATA(0x00);LCD_WR_DATA(0xD3);LCD_WR_DATA(0x00);LCD_WR_DATA(0xDC);LCD_WR_DATA(0x00);LCD_WR_DATA(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xE6);LCD_WR_DATA(0x11);LCD_WR_DATA(0x00);LCD_WR_DATA(0x34);LCD_WR_DATA(0x00);LCD_WR_DATA(0x56);LCD_WR_DATA(0x00);LCD_WR_DATA(0x76);LCD_WR_DATA(0x00);LCD_WR_DATA(0x77);LCD_WR_DATA(0x00);LCD_WR_DATA(0x66);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0xBB);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0x66);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_DATA(0x45);LCD_WR_DATA(0x00);LCD_WR_DATA(0x43);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_REG(0xE7);LCD_WR_DATA(0x32);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_DATA(0x76);LCD_WR_DATA(0x00);LCD_WR_DATA(0x66);LCD_WR_DATA(0x00);LCD_WR_DATA(0x67);LCD_WR_DATA(0x00);LCD_WR_DATA(0x67);LCD_WR_DATA(0x00);LCD_WR_DATA(0x87);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0xBB);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0x77);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x56);LCD_WR_DATA(0x00);LCD_WR_DATA(0x23); LCD_WR_DATA(0x00);LCD_WR_DATA(0x33);LCD_WR_DATA(0x00);LCD_WR_DATA(0x45);LCD_WR_DATA(0x00);LCD_WR_REG(0xE8);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0x87);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_DATA(0x77);LCD_WR_DATA(0x00);LCD_WR_DATA(0x66);LCD_WR_DATA(0x00);LCD_WR_DATA(0x88);LCD_WR_DATA(0x00);LCD_WR_DATA(0xAA);LCD_WR_DATA(0x00);LCD_WR_DATA(0xBB);LCD_WR_DATA(0x00);LCD_WR_DATA(0x99);LCD_WR_DATA(0x00);LCD_WR_DATA(0x66);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x44);LCD_WR_DATA(0x00);LCD_WR_DATA(0x55);LCD_WR_DATA(0x00);LCD_WR_REG(0xE9);LCD_WR_DATA(0xAA);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0x00);LCD_WR_DATA(0xAA);LCD_WR_REG(0xCF);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xF0);LCD_WR_DATA(0x00);LCD_WR_DATA(0x50);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xF3);LCD_WR_DATA(0x00);LCD_WR_REG(0xF9);LCD_WR_DATA(0x06);LCD_WR_DATA(0x10);LCD_WR_DATA(0x29);LCD_WR_DATA(0x00);LCD_WR_REG(0x3A);LCD_WR_DATA(0x55); //66LCD_WR_REG(0x11);delay_ms(100);LCD_WR_REG(0x29);LCD_WR_REG(0x35);LCD_WR_DATA(0x00);LCD_WR_REG(0x51);LCD_WR_DATA(0xFF);LCD_WR_REG(0x53);LCD_WR_DATA(0x2C);LCD_WR_REG(0x55);LCD_WR_DATA(0x82);LCD_WR_REG(0x2c);}else if(lcddev.id==0x5510){LCD_WriteReg(0xF000,0x55);LCD_WriteReg(0xF001,0xAA);LCD_WriteReg(0xF002,0x52);LCD_WriteReg(0xF003,0x08);LCD_WriteReg(0xF004,0x01);//AVDD Set AVDD 5.2VLCD_WriteReg(0xB000,0x0D);LCD_WriteReg(0xB001,0x0D);LCD_WriteReg(0xB002,0x0D);//AVDD ratioLCD_WriteReg(0xB600,0x34);LCD_WriteReg(0xB601,0x34);LCD_WriteReg(0xB602,0x34);//AVEE -5.2VLCD_WriteReg(0xB100,0x0D);LCD_WriteReg(0xB101,0x0D);LCD_WriteReg(0xB102,0x0D);//AVEE ratioLCD_WriteReg(0xB700,0x34);LCD_WriteReg(0xB701,0x34);LCD_WriteReg(0xB702,0x34);//VCL -2.5VLCD_WriteReg(0xB200,0x00);LCD_WriteReg(0xB201,0x00);LCD_WriteReg(0xB202,0x00);//VCL ratioLCD_WriteReg(0xB800,0x24);LCD_WriteReg(0xB801,0x24);LCD_WriteReg(0xB802,0x24);//VGH 15V (Free pump)LCD_WriteReg(0xBF00,0x01);LCD_WriteReg(0xB300,0x0F);LCD_WriteReg(0xB301,0x0F);LCD_WriteReg(0xB302,0x0F);//VGH ratioLCD_WriteReg(0xB900,0x34);LCD_WriteReg(0xB901,0x34);LCD_WriteReg(0xB902,0x34);//VGL_REG -10VLCD_WriteReg(0xB500,0x08);LCD_WriteReg(0xB501,0x08);LCD_WriteReg(0xB502,0x08);LCD_WriteReg(0xC200,0x03);//VGLX ratioLCD_WriteReg(0xBA00,0x24);LCD_WriteReg(0xBA01,0x24);LCD_WriteReg(0xBA02,0x24);//VGMP/VGSP 4.5V/0VLCD_WriteReg(0xBC00,0x00);LCD_WriteReg(0xBC01,0x78);LCD_WriteReg(0xBC02,0x00);//VGMN/VGSN -4.5V/0VLCD_WriteReg(0xBD00,0x00);LCD_WriteReg(0xBD01,0x78);LCD_WriteReg(0xBD02,0x00);//VCOMLCD_WriteReg(0xBE00,0x00);LCD_WriteReg(0xBE01,0x64);//Gamma SettingLCD_WriteReg(0xD100,0x00);LCD_WriteReg(0xD101,0x33);LCD_WriteReg(0xD102,0x00);LCD_WriteReg(0xD103,0x34);LCD_WriteReg(0xD104,0x00);LCD_WriteReg(0xD105,0x3A);LCD_WriteReg(0xD106,0x00);LCD_WriteReg(0xD107,0x4A);LCD_WriteReg(0xD108,0x00);LCD_WriteReg(0xD109,0x5C);LCD_WriteReg(0xD10A,0x00);LCD_WriteReg(0xD10B,0x81);LCD_WriteReg(0xD10C,0x00);LCD_WriteReg(0xD10D,0xA6);LCD_WriteReg(0xD10E,0x00);LCD_WriteReg(0xD10F,0xE5);LCD_WriteReg(0xD110,0x01);LCD_WriteReg(0xD111,0x13);LCD_WriteReg(0xD112,0x01);LCD_WriteReg(0xD113,0x54);LCD_WriteReg(0xD114,0x01);LCD_WriteReg(0xD115,0x82);LCD_WriteReg(0xD116,0x01);LCD_WriteReg(0xD117,0xCA);LCD_WriteReg(0xD118,0x02);LCD_WriteReg(0xD119,0x00);LCD_WriteReg(0xD11A,0x02);LCD_WriteReg(0xD11B,0x01);LCD_WriteReg(0xD11C,0x02);LCD_WriteReg(0xD11D,0x34);LCD_WriteReg(0xD11E,0x02);LCD_WriteReg(0xD11F,0x67);LCD_WriteReg(0xD120,0x02);LCD_WriteReg(0xD121,0x84);LCD_WriteReg(0xD122,0x02);LCD_WriteReg(0xD123,0xA4);LCD_WriteReg(0xD124,0x02);LCD_WriteReg(0xD125,0xB7);LCD_WriteReg(0xD126,0x02);LCD_WriteReg(0xD127,0xCF);LCD_WriteReg(0xD128,0x02);LCD_WriteReg(0xD129,0xDE);LCD_WriteReg(0xD12A,0x02);LCD_WriteReg(0xD12B,0xF2);LCD_WriteReg(0xD12C,0x02);LCD_WriteReg(0xD12D,0xFE);LCD_WriteReg(0xD12E,0x03);LCD_WriteReg(0xD12F,0x10);LCD_WriteReg(0xD130,0x03);LCD_WriteReg(0xD131,0x33);LCD_WriteReg(0xD132,0x03);LCD_WriteReg(0xD133,0x6D);LCD_WriteReg(0xD200,0x00);LCD_WriteReg(0xD201,0x33);LCD_WriteReg(0xD202,0x00);LCD_WriteReg(0xD203,0x34);LCD_WriteReg(0xD204,0x00);LCD_WriteReg(0xD205,0x3A);LCD_WriteReg(0xD206,0x00);LCD_WriteReg(0xD207,0x4A);LCD_WriteReg(0xD208,0x00);LCD_WriteReg(0xD209,0x5C);LCD_WriteReg(0xD20A,0x00);LCD_WriteReg(0xD20B,0x81);LCD_WriteReg(0xD20C,0x00);LCD_WriteReg(0xD20D,0xA6);LCD_WriteReg(0xD20E,0x00);LCD_WriteReg(0xD20F,0xE5);LCD_WriteReg(0xD210,0x01);LCD_WriteReg(0xD211,0x13);LCD_WriteReg(0xD212,0x01);LCD_WriteReg(0xD213,0x54);LCD_WriteReg(0xD214,0x01);LCD_WriteReg(0xD215,0x82);LCD_WriteReg(0xD216,0x01);LCD_WriteReg(0xD217,0xCA);LCD_WriteReg(0xD218,0x02);LCD_WriteReg(0xD219,0x00);LCD_WriteReg(0xD21A,0x02);LCD_WriteReg(0xD21B,0x01);LCD_WriteReg(0xD21C,0x02);LCD_WriteReg(0xD21D,0x34);LCD_WriteReg(0xD21E,0x02);LCD_WriteReg(0xD21F,0x67);LCD_WriteReg(0xD220,0x02);LCD_WriteReg(0xD221,0x84);LCD_WriteReg(0xD222,0x02);LCD_WriteReg(0xD223,0xA4);LCD_WriteReg(0xD224,0x02);LCD_WriteReg(0xD225,0xB7);LCD_WriteReg(0xD226,0x02);LCD_WriteReg(0xD227,0xCF);LCD_WriteReg(0xD228,0x02);LCD_WriteReg(0xD229,0xDE);LCD_WriteReg(0xD22A,0x02);LCD_WriteReg(0xD22B,0xF2);LCD_WriteReg(0xD22C,0x02);LCD_WriteReg(0xD22D,0xFE);LCD_WriteReg(0xD22E,0x03);LCD_WriteReg(0xD22F,0x10);LCD_WriteReg(0xD230,0x03);LCD_WriteReg(0xD231,0x33);LCD_WriteReg(0xD232,0x03);LCD_WriteReg(0xD233,0x6D);LCD_WriteReg(0xD300,0x00);LCD_WriteReg(0xD301,0x33);LCD_WriteReg(0xD302,0x00);LCD_WriteReg(0xD303,0x34);LCD_WriteReg(0xD304,0x00);LCD_WriteReg(0xD305,0x3A);LCD_WriteReg(0xD306,0x00);LCD_WriteReg(0xD307,0x4A);LCD_WriteReg(0xD308,0x00);LCD_WriteReg(0xD309,0x5C);LCD_WriteReg(0xD30A,0x00);LCD_WriteReg(0xD30B,0x81);LCD_WriteReg(0xD30C,0x00);LCD_WriteReg(0xD30D,0xA6);LCD_WriteReg(0xD30E,0x00);LCD_WriteReg(0xD30F,0xE5);LCD_WriteReg(0xD310,0x01);LCD_WriteReg(0xD311,0x13);LCD_WriteReg(0xD312,0x01);LCD_WriteReg(0xD313,0x54);LCD_WriteReg(0xD314,0x01);LCD_WriteReg(0xD315,0x82);LCD_WriteReg(0xD316,0x01);LCD_WriteReg(0xD317,0xCA);LCD_WriteReg(0xD318,0x02);LCD_WriteReg(0xD319,0x00);LCD_WriteReg(0xD31A,0x02);LCD_WriteReg(0xD31B,0x01);LCD_WriteReg(0xD31C,0x02);LCD_WriteReg(0xD31D,0x34);LCD_WriteReg(0xD31E,0x02);LCD_WriteReg(0xD31F,0x67);LCD_WriteReg(0xD320,0x02);LCD_WriteReg(0xD321,0x84);LCD_WriteReg(0xD322,0x02);LCD_WriteReg(0xD323,0xA4);LCD_WriteReg(0xD324,0x02);LCD_WriteReg(0xD325,0xB7);LCD_WriteReg(0xD326,0x02);LCD_WriteReg(0xD327,0xCF);LCD_WriteReg(0xD328,0x02);LCD_WriteReg(0xD329,0xDE);LCD_WriteReg(0xD32A,0x02);LCD_WriteReg(0xD32B,0xF2);LCD_WriteReg(0xD32C,0x02);LCD_WriteReg(0xD32D,0xFE);LCD_WriteReg(0xD32E,0x03);LCD_WriteReg(0xD32F,0x10);LCD_WriteReg(0xD330,0x03);LCD_WriteReg(0xD331,0x33);LCD_WriteReg(0xD332,0x03);LCD_WriteReg(0xD333,0x6D);LCD_WriteReg(0xD400,0x00);LCD_WriteReg(0xD401,0x33);LCD_WriteReg(0xD402,0x00);LCD_WriteReg(0xD403,0x34);LCD_WriteReg(0xD404,0x00);LCD_WriteReg(0xD405,0x3A);LCD_WriteReg(0xD406,0x00);LCD_WriteReg(0xD407,0x4A);LCD_WriteReg(0xD408,0x00);LCD_WriteReg(0xD409,0x5C);LCD_WriteReg(0xD40A,0x00);LCD_WriteReg(0xD40B,0x81);LCD_WriteReg(0xD40C,0x00);LCD_WriteReg(0xD40D,0xA6);LCD_WriteReg(0xD40E,0x00);LCD_WriteReg(0xD40F,0xE5);LCD_WriteReg(0xD410,0x01);LCD_WriteReg(0xD411,0x13);LCD_WriteReg(0xD412,0x01);LCD_WriteReg(0xD413,0x54);LCD_WriteReg(0xD414,0x01);LCD_WriteReg(0xD415,0x82);LCD_WriteReg(0xD416,0x01);LCD_WriteReg(0xD417,0xCA);LCD_WriteReg(0xD418,0x02);LCD_WriteReg(0xD419,0x00);LCD_WriteReg(0xD41A,0x02);LCD_WriteReg(0xD41B,0x01);LCD_WriteReg(0xD41C,0x02);LCD_WriteReg(0xD41D,0x34);LCD_WriteReg(0xD41E,0x02);LCD_WriteReg(0xD41F,0x67);LCD_WriteReg(0xD420,0x02);LCD_WriteReg(0xD421,0x84);LCD_WriteReg(0xD422,0x02);LCD_WriteReg(0xD423,0xA4);LCD_WriteReg(0xD424,0x02);LCD_WriteReg(0xD425,0xB7);LCD_WriteReg(0xD426,0x02);LCD_WriteReg(0xD427,0xCF);LCD_WriteReg(0xD428,0x02);LCD_WriteReg(0xD429,0xDE);LCD_WriteReg(0xD42A,0x02);LCD_WriteReg(0xD42B,0xF2);LCD_WriteReg(0xD42C,0x02);LCD_WriteReg(0xD42D,0xFE);LCD_WriteReg(0xD42E,0x03);LCD_WriteReg(0xD42F,0x10);LCD_WriteReg(0xD430,0x03);LCD_WriteReg(0xD431,0x33);LCD_WriteReg(0xD432,0x03);LCD_WriteReg(0xD433,0x6D);LCD_WriteReg(0xD500,0x00);LCD_WriteReg(0xD501,0x33);LCD_WriteReg(0xD502,0x00);LCD_WriteReg(0xD503,0x34);LCD_WriteReg(0xD504,0x00);LCD_WriteReg(0xD505,0x3A);LCD_WriteReg(0xD506,0x00);LCD_WriteReg(0xD507,0x4A);LCD_WriteReg(0xD508,0x00);LCD_WriteReg(0xD509,0x5C);LCD_WriteReg(0xD50A,0x00);LCD_WriteReg(0xD50B,0x81);LCD_WriteReg(0xD50C,0x00);LCD_WriteReg(0xD50D,0xA6);LCD_WriteReg(0xD50E,0x00);LCD_WriteReg(0xD50F,0xE5);LCD_WriteReg(0xD510,0x01);LCD_WriteReg(0xD511,0x13);LCD_WriteReg(0xD512,0x01);LCD_WriteReg(0xD513,0x54);LCD_WriteReg(0xD514,0x01);LCD_WriteReg(0xD515,0x82);LCD_WriteReg(0xD516,0x01);LCD_WriteReg(0xD517,0xCA);LCD_WriteReg(0xD518,0x02);LCD_WriteReg(0xD519,0x00);LCD_WriteReg(0xD51A,0x02);LCD_WriteReg(0xD51B,0x01);LCD_WriteReg(0xD51C,0x02);LCD_WriteReg(0xD51D,0x34);LCD_WriteReg(0xD51E,0x02);LCD_WriteReg(0xD51F,0x67);LCD_WriteReg(0xD520,0x02);LCD_WriteReg(0xD521,0x84);LCD_WriteReg(0xD522,0x02);LCD_WriteReg(0xD523,0xA4);LCD_WriteReg(0xD524,0x02);LCD_WriteReg(0xD525,0xB7);LCD_WriteReg(0xD526,0x02);LCD_WriteReg(0xD527,0xCF);LCD_WriteReg(0xD528,0x02);LCD_WriteReg(0xD529,0xDE);LCD_WriteReg(0xD52A,0x02);LCD_WriteReg(0xD52B,0xF2);LCD_WriteReg(0xD52C,0x02);LCD_WriteReg(0xD52D,0xFE);LCD_WriteReg(0xD52E,0x03);LCD_WriteReg(0xD52F,0x10);LCD_WriteReg(0xD530,0x03);LCD_WriteReg(0xD531,0x33);LCD_WriteReg(0xD532,0x03);LCD_WriteReg(0xD533,0x6D);LCD_WriteReg(0xD600,0x00);LCD_WriteReg(0xD601,0x33);LCD_WriteReg(0xD602,0x00);LCD_WriteReg(0xD603,0x34);LCD_WriteReg(0xD604,0x00);LCD_WriteReg(0xD605,0x3A);LCD_WriteReg(0xD606,0x00);LCD_WriteReg(0xD607,0x4A);LCD_WriteReg(0xD608,0x00);LCD_WriteReg(0xD609,0x5C);LCD_WriteReg(0xD60A,0x00);LCD_WriteReg(0xD60B,0x81);LCD_WriteReg(0xD60C,0x00);LCD_WriteReg(0xD60D,0xA6);LCD_WriteReg(0xD60E,0x00);LCD_WriteReg(0xD60F,0xE5);LCD_WriteReg(0xD610,0x01);LCD_WriteReg(0xD611,0x13);LCD_WriteReg(0xD612,0x01);LCD_WriteReg(0xD613,0x54);LCD_WriteReg(0xD614,0x01);LCD_WriteReg(0xD615,0x82);LCD_WriteReg(0xD616,0x01);LCD_WriteReg(0xD617,0xCA);LCD_WriteReg(0xD618,0x02);LCD_WriteReg(0xD619,0x00);LCD_WriteReg(0xD61A,0x02);LCD_WriteReg(0xD61B,0x01);LCD_WriteReg(0xD61C,0x02);LCD_WriteReg(0xD61D,0x34);LCD_WriteReg(0xD61E,0x02);LCD_WriteReg(0xD61F,0x67);LCD_WriteReg(0xD620,0x02);LCD_WriteReg(0xD621,0x84);LCD_WriteReg(0xD622,0x02);LCD_WriteReg(0xD623,0xA4);LCD_WriteReg(0xD624,0x02);LCD_WriteReg(0xD625,0xB7);LCD_WriteReg(0xD626,0x02);LCD_WriteReg(0xD627,0xCF);LCD_WriteReg(0xD628,0x02);LCD_WriteReg(0xD629,0xDE);LCD_WriteReg(0xD62A,0x02);LCD_WriteReg(0xD62B,0xF2);LCD_WriteReg(0xD62C,0x02);LCD_WriteReg(0xD62D,0xFE);LCD_WriteReg(0xD62E,0x03);LCD_WriteReg(0xD62F,0x10);LCD_WriteReg(0xD630,0x03);LCD_WriteReg(0xD631,0x33);LCD_WriteReg(0xD632,0x03);LCD_WriteReg(0xD633,0x6D);//LV2 Page 0 enableLCD_WriteReg(0xF000,0x55);LCD_WriteReg(0xF001,0xAA);LCD_WriteReg(0xF002,0x52);LCD_WriteReg(0xF003,0x08);LCD_WriteReg(0xF004,0x00);//Display controlLCD_WriteReg(0xB100, 0xCC);LCD_WriteReg(0xB101, 0x00);//Source hold timeLCD_WriteReg(0xB600,0x05);//Gate EQ controlLCD_WriteReg(0xB700,0x70);LCD_WriteReg(0xB701,0x70);//Source EQ control (Mode 2)LCD_WriteReg(0xB800,0x01);LCD_WriteReg(0xB801,0x03);LCD_WriteReg(0xB802,0x03);LCD_WriteReg(0xB803,0x03);//Inversion mode (2-dot)LCD_WriteReg(0xBC00,0x02);LCD_WriteReg(0xBC01,0x00);LCD_WriteReg(0xBC02,0x00);//Timing control 4H w/ 4-delayLCD_WriteReg(0xC900,0xD0);LCD_WriteReg(0xC901,0x02);LCD_WriteReg(0xC902,0x50);LCD_WriteReg(0xC903,0x50);LCD_WriteReg(0xC904,0x50);LCD_WriteReg(0x3500,0x00);LCD_WriteReg(0x3A00,0x55); //16-bit/pixelLCD_WR_REG(0x1100);delay_us(120);LCD_WR_REG(0x2900);}else if(lcddev.id==0x9325)//9325{LCD_WriteReg(0x00E5,0x78F0); LCD_WriteReg(0x0001,0x0100); LCD_WriteReg(0x0002,0x0700); LCD_WriteReg(0x0003,0x1030); LCD_WriteReg(0x0004,0x0000); LCD_WriteReg(0x0008,0x0202); LCD_WriteReg(0x0009,0x0000);LCD_WriteReg(0x000A,0x0000); LCD_WriteReg(0x000C,0x0000); LCD_WriteReg(0x000D,0x0000);LCD_WriteReg(0x000F,0x0000);//power on sequence VGHVGLLCD_WriteReg(0x0010,0x0000); LCD_WriteReg(0x0011,0x0007); LCD_WriteReg(0x0012,0x0000); LCD_WriteReg(0x0013,0x0000); LCD_WriteReg(0x0007,0x0000); //vgh LCD_WriteReg(0x0010,0x1690); LCD_WriteReg(0x0011,0x0227);//delayms(100);//vregiout LCD_WriteReg(0x0012,0x009D); //0x001b//delayms(100); //vom amplitudeLCD_WriteReg(0x0013,0x1900);//delayms(100); //vom HLCD_WriteReg(0x0029,0x0025); LCD_WriteReg(0x002B,0x000D); //gammaLCD_WriteReg(0x0030,0x0007);LCD_WriteReg(0x0031,0x0303);LCD_WriteReg(0x0032,0x0003);// 0006LCD_WriteReg(0x0035,0x0206);LCD_WriteReg(0x0036,0x0008);LCD_WriteReg(0x0037,0x0406); LCD_WriteReg(0x0038,0x0304);//0200LCD_WriteReg(0x0039,0x0007); LCD_WriteReg(0x003C,0x0602);// 0504LCD_WriteReg(0x003D,0x0008); //ramLCD_WriteReg(0x0050,0x0000); LCD_WriteReg(0x0051,0x00EF);LCD_WriteReg(0x0052,0x0000); LCD_WriteReg(0x0053,0x013F); LCD_WriteReg(0x0060,0xA700); LCD_WriteReg(0x0061,0x0001); LCD_WriteReg(0x006A,0x0000); //LCD_WriteReg(0x0080,0x0000); LCD_WriteReg(0x0081,0x0000); LCD_WriteReg(0x0082,0x0000); LCD_WriteReg(0x0083,0x0000); LCD_WriteReg(0x0084,0x0000); LCD_WriteReg(0x0085,0x0000); //LCD_WriteReg(0x0090,0x0010); LCD_WriteReg(0x0092,0x0600); LCD_WriteReg(0x0007,0x0133);LCD_WriteReg(0x00,0x0022);//}else if(lcddev.id==0x9328)//ILI9328 OK {LCD_WriteReg(0x00EC,0x108F);// internal timeing LCD_WriteReg(0x00EF,0x1234);// ADD //LCD_WriteReg(0x00e7,0x0010); //LCD_WriteReg(0x0000,0x0001);//开启内部时钟LCD_WriteReg(0x0001,0x0100); LCD_WriteReg(0x0002,0x0700);//电源开启 //LCD_WriteReg(0x0003,(1<<3)|(1<<4) ); //65K RGB//DRIVE TABLE(寄存器 03H)//BIT3=AM BIT4:5=ID0:1//AM ID0 ID1 FUNCATION// 0 0 0 R->L D->U// 1 0 0 D->U R->L// 0 1 0 L->R D->U// 1 1 0 D->U L->R// 0 0 1 R->L U->D// 1 0 1 U->D R->L// 0 1 1 L->R U->D 正常就用这个.// 1 1 1 U->D L->RLCD_WriteReg(0x0003,(1<<12)|(3<<4)|(0<<3) );//65K LCD_WriteReg(0x0004,0x0000); LCD_WriteReg(0x0008,0x0202); LCD_WriteReg(0x0009,0x0000); LCD_WriteReg(0x000a,0x0000);//display setting LCD_WriteReg(0x000c,0x0001);//display setting LCD_WriteReg(0x000d,0x0000);//0f3c LCD_WriteReg(0x000f,0x0000);//电源配置LCD_WriteReg(0x0010,0x0000); LCD_WriteReg(0x0011,0x0007);LCD_WriteReg(0x0012,0x0000); LCD_WriteReg(0x0013,0x0000); LCD_WriteReg(0x0007,0x0001); delay_ms(50); LCD_WriteReg(0x0010,0x1490); LCD_WriteReg(0x0011,0x0227);delay_ms(50); LCD_WriteReg(0x0012,0x008A); delay_ms(50); LCD_WriteReg(0x0013,0x1a00); LCD_WriteReg(0x0029,0x0006);LCD_WriteReg(0x002b,0x000d);delay_ms(50); LCD_WriteReg(0x0020,0x0000); LCD_WriteReg(0x0021,0x0000); delay_ms(50); //伽马校正LCD_WriteReg(0x0030,0x0000); LCD_WriteReg(0x0031,0x0604); LCD_WriteReg(0x0032,0x0305);LCD_WriteReg(0x0035,0x0000);LCD_WriteReg(0x0036,0x0C09); LCD_WriteReg(0x0037,0x0204);LCD_WriteReg(0x0038,0x0301); LCD_WriteReg(0x0039,0x0707); LCD_WriteReg(0x003c,0x0000);LCD_WriteReg(0x003d,0x0a0a);delay_ms(50); LCD_WriteReg(0x0050,0x0000); //水平GRAM起始位置 LCD_WriteReg(0x0051,0x00ef); //水平GRAM终止位置 LCD_WriteReg(0x0052,0x0000); //垂直GRAM起始位置 LCD_WriteReg(0x0053,0x013f); //垂直GRAM终止位置 LCD_WriteReg(0x0060,0xa700); LCD_WriteReg(0x0061,0x0001); LCD_WriteReg(0x006a,0x0000);LCD_WriteReg(0x0080,0x0000);LCD_WriteReg(0x0081,0x0000);LCD_WriteReg(0x0082,0x0000);LCD_WriteReg(0x0083,0x0000);LCD_WriteReg(0x0084,0x0000);LCD_WriteReg(0x0085,0x0000);LCD_WriteReg(0x0090,0x0010); LCD_WriteReg(0x0092,0x0600); //开启显示设置 LCD_WriteReg(0x0007,0x0133); }else if(lcddev.id==0x9320)//测试OK.{LCD_WriteReg(0x00,0x0000);LCD_WriteReg(0x01,0x0100); //Driver Output Contral.LCD_WriteReg(0x02,0x0700); //LCD Driver Waveform Contral.LCD_WriteReg(0x03,0x1030);//Entry Mode Set.//LCD_WriteReg(0x03,0x1018); //Entry Mode Set.LCD_WriteReg(0x04,0x0000); //Scalling Contral.LCD_WriteReg(0x08,0x0202); //Display Contral 2.(0x0207)LCD_WriteReg(0x09,0x0000); //Display Contral 3.(0x0000)LCD_WriteReg(0x0a,0x0000); //Frame Cycle Contal.(0x0000)LCD_WriteReg(0x0c,(1<<0)); //Extern Display Interface Contral 1.(0x0000)LCD_WriteReg(0x0d,0x0000); //Frame Maker Position.LCD_WriteReg(0x0f,0x0000); //Extern Display Interface Contral 2. delay_ms(50); LCD_WriteReg(0x07,0x0101); //Display Contral.delay_ms(50); LCD_WriteReg(0x10,(1<<12)|(0<<8)|(1<<7)|(1<<6)|(0<<4)); //Power Control 1.(0x16b0)LCD_WriteReg(0x11,0x0007); //Power Control 2.(0x0001)LCD_WriteReg(0x12,(1<<8)|(1<<4)|(0<<0)); //Power Control 3.(0x0138)LCD_WriteReg(0x13,0x0b00); //Power Control 4.LCD_WriteReg(0x29,0x0000); //Power Control 7.LCD_WriteReg(0x2b,(1<<14)|(1<<4)); LCD_WriteReg(0x50,0); //Set X Star//水平GRAM终止位置Set X End.LCD_WriteReg(0x51,239); //Set Y StarLCD_WriteReg(0x52,0); //Set Y End.t.LCD_WriteReg(0x53,319); //LCD_WriteReg(0x60,0x2700); //Driver Output Control.LCD_WriteReg(0x61,0x0001); //Driver Output Control.LCD_WriteReg(0x6a,0x0000); //Vertical Srcoll Control.LCD_WriteReg(0x80,0x0000); //Display Position? Partial Display 1.LCD_WriteReg(0x81,0x0000); //RAM Address Start? Partial Display 1.LCD_WriteReg(0x82,0x0000); //RAM Address End-Partial Display 1.LCD_WriteReg(0x83,0x0000); //Displsy Position? Partial Display 2.LCD_WriteReg(0x84,0x0000); //RAM Address Start? Partial Display 2.LCD_WriteReg(0x85,0x0000); //RAM Address End? Partial Display 2.LCD_WriteReg(0x90,(0<<7)|(16<<0)); //Frame Cycle Contral.(0x0013)LCD_WriteReg(0x92,0x0000); //Panel Interface Contral 2.(0x0000)LCD_WriteReg(0x93,0x0001); //Panel Interface Contral 3.LCD_WriteReg(0x95,0x0110); //Frame Cycle Contral.(0x0110)LCD_WriteReg(0x97,(0<<8)); //LCD_WriteReg(0x98,0x0000); //Frame Cycle Contral. LCD_WriteReg(0x07,0x0173); //(0x0173)}else if(lcddev.id==0X9331)//OK |/|/| {LCD_WriteReg(0x00E7, 0x1014);LCD_WriteReg(0x0001, 0x0100); // set SS and SM bitLCD_WriteReg(0x0002, 0x0200); // set 1 line inversionLCD_WriteReg(0x0003,(1<<12)|(3<<4)|(1<<3));//65K //LCD_WriteReg(0x0003, 0x1030); // set GRAM write direction and BGR=1.LCD_WriteReg(0x0008, 0x0202); // set the back porch and front porchLCD_WriteReg(0x0009, 0x0000); // set non-display area refresh cycle ISC[3:0]LCD_WriteReg(0x000A, 0x0000); // FMARK functionLCD_WriteReg(0x000C, 0x0000); // RGB interface settingLCD_WriteReg(0x000D, 0x0000); // Frame marker PositionLCD_WriteReg(0x000F, 0x0000); // RGB interface polarity//*************Power On sequence ****************//LCD_WriteReg(0x0010, 0x0000); // SAP, BT[3:0], AP, DSTB, SLP, STBLCD_WriteReg(0x0011, 0x0007); // DC1[2:0], DC0[2:0], VC[2:0]LCD_WriteReg(0x0012, 0x0000); // VREG1OUT voltageLCD_WriteReg(0x0013, 0x0000); // VDV[4:0] for VCOM amplitudedelay_ms(200); // Dis-charge capacitor power voltageLCD_WriteReg(0x0010, 0x1690); // SAP, BT[3:0], AP, DSTB, SLP, STBLCD_WriteReg(0x0011, 0x0227); // DC1[2:0], DC0[2:0], VC[2:0]delay_ms(50); // Delay 50msLCD_WriteReg(0x0012, 0x000C); // Internal reference voltage= Vci;delay_ms(50); // Delay 50msLCD_WriteReg(0x0013, 0x0800); // Set VDV[4:0] for VCOM amplitudeLCD_WriteReg(0x0029, 0x0011); // Set VCM[5:0] for VCOMHLCD_WriteReg(0x002B, 0x000B); // Set Frame Ratedelay_ms(50); // Delay 50msLCD_WriteReg(0x0020, 0x0000); // GRAM horizontal AddressLCD_WriteReg(0x0021, 0x013f); // GRAM Vertical Address// ----------- Adjust the Gamma Curve ----------//LCD_WriteReg(0x0030, 0x0000);LCD_WriteReg(0x0031, 0x0106);LCD_WriteReg(0x0032, 0x0000);LCD_WriteReg(0x0035, 0x0204);LCD_WriteReg(0x0036, 0x160A);LCD_WriteReg(0x0037, 0x0707);LCD_WriteReg(0x0038, 0x0106);LCD_WriteReg(0x0039, 0x0707);LCD_WriteReg(0x003C, 0x0402);LCD_WriteReg(0x003D, 0x0C0F);//------------------ Set GRAM area ---------------//LCD_WriteReg(0x0050, 0x0000); // Horizontal GRAM Start AddressLCD_WriteReg(0x0051, 0x00EF); // Horizontal GRAM End AddressLCD_WriteReg(0x0052, 0x0000); // Vertical GRAM Start AddressLCD_WriteReg(0x0053, 0x013F); // Vertical GRAM Start AddressLCD_WriteReg(0x0060, 0x2700); // Gate Scan LineLCD_WriteReg(0x0061, 0x0001); // NDL,VLE, REV LCD_WriteReg(0x006A, 0x0000); // set scrolling line//-------------- Partial Display Control ---------//LCD_WriteReg(0x0080, 0x0000);LCD_WriteReg(0x0081, 0x0000);LCD_WriteReg(0x0082, 0x0000);LCD_WriteReg(0x0083, 0x0000);LCD_WriteReg(0x0084, 0x0000);LCD_WriteReg(0x0085, 0x0000);//-------------- Panel Control -------------------//LCD_WriteReg(0x0090, 0x0010);LCD_WriteReg(0x0092, 0x0600);LCD_WriteReg(0x0007, 0x0133); // 262K color and display ON}else if(lcddev.id==0x5408){LCD_WriteReg(0x01,0x0100); LCD_WriteReg(0x02,0x0700);//LCD Driving Waveform Contral LCD_WriteReg(0x03,0x1030);//Entry Mode设置 //指针从左至右自上而下的自动增模式//Normal Mode(Window Mode disable)//RGB格式//16位数据2次传输的8总线设置LCD_WriteReg(0x04,0x0000); //Scalling Control register LCD_WriteReg(0x08,0x0207); //Display Control 2 LCD_WriteReg(0x09,0x0000); //Display Control 3 LCD_WriteReg(0x0A,0x0000); //Frame Cycle Control LCD_WriteReg(0x0C,0x0000); //External Display Interface Control 1 LCD_WriteReg(0x0D,0x0000); //Frame Maker Position LCD_WriteReg(0x0F,0x0000); //External Display Interface Control 2 delay_ms(20);//TFT 液晶彩色图像显示方法14LCD_WriteReg(0x10,0x16B0); //0x14B0 //Power Control 1LCD_WriteReg(0x11,0x0001); //0x0007 //Power Control 2LCD_WriteReg(0x17,0x0001); //0x0000 //Power Control 3LCD_WriteReg(0x12,0x0138); //0x013B //Power Control 4LCD_WriteReg(0x13,0x0800); //0x0800 //Power Control 5LCD_WriteReg(0x29,0x0009); //NVM read data 2LCD_WriteReg(0x2a,0x0009); //NVM read data 3LCD_WriteReg(0xa4,0x0000); LCD_WriteReg(0x50,0x0000); //设置操作窗口的X轴开始列LCD_WriteReg(0x51,0x00EF); //设置操作窗口的X轴结束列LCD_WriteReg(0x52,0x0000); //设置操作窗口的Y轴开始行LCD_WriteReg(0x53,0x013F); //设置操作窗口的Y轴结束行LCD_WriteReg(0x60,0x2700); //Driver Output Control//设置屏幕的点数以及扫描的起始行LCD_WriteReg(0x61,0x0001); //Driver Output ControlLCD_WriteReg(0x6A,0x0000); //Vertical Scroll ControlLCD_WriteReg(0x80,0x0000); //Display Position – Partial Display 1LCD_WriteReg(0x81,0x0000); //RAM Address Start – Partial Display 1LCD_WriteReg(0x82,0x0000); //RAM address End - Partial Display 1LCD_WriteReg(0x83,0x0000); //Display Position – Partial Display 2LCD_WriteReg(0x84,0x0000); //RAM Address Start – Partial Display 2LCD_WriteReg(0x85,0x0000); //RAM address End – Partail Display2LCD_WriteReg(0x90,0x0013); //Frame Cycle ControlLCD_WriteReg(0x92,0x0000); //Panel Interface Control 2LCD_WriteReg(0x93,0x0003); //Panel Interface control 3LCD_WriteReg(0x95,0x0110); //Frame Cycle ControlLCD_WriteReg(0x07,0x0173); delay_ms(50);} else if(lcddev.id==0x1505)//OK{// second release on 3/5 ,luminance is acceptable,water wave appear during camera previewLCD_WriteReg(0x0007,0x0000);delay_ms(50); LCD_WriteReg(0x0012,0x011C);//0x011A why need to set several times?LCD_WriteReg(0x00A4,0x0001);//NVM LCD_WriteReg(0x0008,0x000F);LCD_WriteReg(0x000A,0x0008);LCD_WriteReg(0x000D,0x0008); //伽马校正LCD_WriteReg(0x0030,0x0707);LCD_WriteReg(0x0031,0x0007); //0x0707LCD_WriteReg(0x0032,0x0603); LCD_WriteReg(0x0033,0x0700); LCD_WriteReg(0x0034,0x0202); LCD_WriteReg(0x0035,0x0002); //?0x0606LCD_WriteReg(0x0036,0x1F0F);LCD_WriteReg(0x0037,0x0707); //0x0f0f 0x0105LCD_WriteReg(0x0038,0x0000); LCD_WriteReg(0x0039,0x0000); LCD_WriteReg(0x003A,0x0707); LCD_WriteReg(0x003B,0x0000); //0x0303LCD_WriteReg(0x003C,0x0007); //?0x0707LCD_WriteReg(0x003D,0x0000); //0x1313//0x1f08delay_ms(50); LCD_WriteReg(0x0007,0x0001);LCD_WriteReg(0x0017,0x0001);//开启电源delay_ms(50); //电源配置LCD_WriteReg(0x0010,0x17A0); LCD_WriteReg(0x0011,0x0217);//reference voltage VC[2:0] Vciout = 1.00*VcivlLCD_WriteReg(0x0012,0x011E);//0x011c //Vreg1out = Vcilvl*1.80 is it the same as Vgama1out ?LCD_WriteReg(0x0013,0x0F00);//VDV[4:0]-->VCOM Amplitude VcomL = VcomH - Vcom AmplLCD_WriteReg(0x002A,0x0000); LCD_WriteReg(0x0029,0x000A);//0x0001F Vcomh = VCM1[4:0]*Vreg1out gate source voltage??LCD_WriteReg(0x0012,0x013E);// 0x013C power supply on//Coordinates Control//LCD_WriteReg(0x0050,0x0000);//0x0e00LCD_WriteReg(0x0051,0x00EF); LCD_WriteReg(0x0052,0x0000); LCD_WriteReg(0x0053,0x013F); //Pannel Image Control//LCD_WriteReg(0x0060,0x2700); LCD_WriteReg(0x0061,0x0001); LCD_WriteReg(0x006A,0x0000); LCD_WriteReg(0x0080,0x0000); //Partial Image Control//LCD_WriteReg(0x0081,0x0000); LCD_WriteReg(0x0082,0x0000); LCD_WriteReg(0x0083,0x0000); LCD_WriteReg(0x0084,0x0000); LCD_WriteReg(0x0085,0x0000); //Panel Interface Control//LCD_WriteReg(0x0090,0x0013);//0x0010 frenqucyLCD_WriteReg(0x0092,0x0300); LCD_WriteReg(0x0093,0x0005); LCD_WriteReg(0x0095,0x0000); LCD_WriteReg(0x0097,0x0000); LCD_WriteReg(0x0098,0x0000); LCD_WriteReg(0x0001,0x0100); LCD_WriteReg(0x0002,0x0700); LCD_WriteReg(0x0003,0x1038);//扫描方向 上->下 左->右 LCD_WriteReg(0x0004,0x0000); LCD_WriteReg(0x000C,0x0000); LCD_WriteReg(0x000F,0x0000); LCD_WriteReg(0x0020,0x0000); LCD_WriteReg(0x0021,0x0000); LCD_WriteReg(0x0007,0x0021); delay_ms(20);LCD_WriteReg(0x0007,0x0061); delay_ms(20);LCD_WriteReg(0x0007,0x0173); delay_ms(20);}else if(lcddev.id==0xB505){LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x00a4,0x0001);delay_ms(20); LCD_WriteReg(0x0060,0x2700);LCD_WriteReg(0x0008,0x0202);LCD_WriteReg(0x0030,0x0214);LCD_WriteReg(0x0031,0x3715);LCD_WriteReg(0x0032,0x0604);LCD_WriteReg(0x0033,0x0e16);LCD_WriteReg(0x0034,0x2211);LCD_WriteReg(0x0035,0x1500);LCD_WriteReg(0x0036,0x8507);LCD_WriteReg(0x0037,0x1407);LCD_WriteReg(0x0038,0x1403);LCD_WriteReg(0x0039,0x0020);LCD_WriteReg(0x0090,0x001a);LCD_WriteReg(0x0010,0x0000);LCD_WriteReg(0x0011,0x0007);LCD_WriteReg(0x0012,0x0000);LCD_WriteReg(0x0013,0x0000);delay_ms(20);LCD_WriteReg(0x0010,0x0730);LCD_WriteReg(0x0011,0x0137);delay_ms(20);LCD_WriteReg(0x0012,0x01b8);delay_ms(20);LCD_WriteReg(0x0013,0x0f00);LCD_WriteReg(0x002a,0x0080);LCD_WriteReg(0x0029,0x0048);delay_ms(20);LCD_WriteReg(0x0001,0x0100);LCD_WriteReg(0x0002,0x0700);LCD_WriteReg(0x0003,0x1038);//扫描方向 上->下 左->右 LCD_WriteReg(0x0008,0x0202);LCD_WriteReg(0x000a,0x0000);LCD_WriteReg(0x000c,0x0000);LCD_WriteReg(0x000d,0x0000);LCD_WriteReg(0x000e,0x0030);LCD_WriteReg(0x0050,0x0000);LCD_WriteReg(0x0051,0x00ef);LCD_WriteReg(0x0052,0x0000);LCD_WriteReg(0x0053,0x013f);LCD_WriteReg(0x0060,0x2700);LCD_WriteReg(0x0061,0x0001);LCD_WriteReg(0x006a,0x0000);//LCD_WriteReg(0x0080,0x0000);//LCD_WriteReg(0x0081,0x0000);LCD_WriteReg(0x0090,0X0011);LCD_WriteReg(0x0092,0x0600);LCD_WriteReg(0x0093,0x0402);LCD_WriteReg(0x0094,0x0002);delay_ms(20);LCD_WriteReg(0x0007,0x0001);delay_ms(20);LCD_WriteReg(0x0007,0x0061);LCD_WriteReg(0x0007,0x0173);LCD_WriteReg(0x0020,0x0000);LCD_WriteReg(0x0021,0x0000); LCD_WriteReg(0x00,0x22); }else if(lcddev.id==0xC505){LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);delay_ms(20); LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x0000,0x0000);LCD_WriteReg(0x00a4,0x0001);delay_ms(20); LCD_WriteReg(0x0060,0x2700);LCD_WriteReg(0x0008,0x0806);LCD_WriteReg(0x0030,0x0703);//gamma settingLCD_WriteReg(0x0031,0x0001);LCD_WriteReg(0x0032,0x0004);LCD_WriteReg(0x0033,0x0102);LCD_WriteReg(0x0034,0x0300);LCD_WriteReg(0x0035,0x0103);LCD_WriteReg(0x0036,0x001F);LCD_WriteReg(0x0037,0x0703);LCD_WriteReg(0x0038,0x0001);LCD_WriteReg(0x0039,0x0004);LCD_WriteReg(0x0090, 0x0015); //80HzLCD_WriteReg(0x0010, 0X0410); //BT,APLCD_WriteReg(0x0011,0x0247); //DC1,DC0,VCLCD_WriteReg(0x0012, 0x01BC);LCD_WriteReg(0x0013, 0x0e00);delay_ms(120);LCD_WriteReg(0x0001, 0x0100);LCD_WriteReg(0x0002, 0x0200);LCD_WriteReg(0x0003, 0x1030);LCD_WriteReg(0x000A, 0x0008);LCD_WriteReg(0x000C, 0x0000);LCD_WriteReg(0x000E, 0x0020);LCD_WriteReg(0x000F, 0x0000);LCD_WriteReg(0x0020, 0x0000); //H StartLCD_WriteReg(0x0021, 0x0000); //V StartLCD_WriteReg(0x002A,0x003D); //vcom2delay_ms(20);LCD_WriteReg(0x0029, 0x002d);LCD_WriteReg(0x0050, 0x0000);LCD_WriteReg(0x0051, 0xD0EF);LCD_WriteReg(0x0052, 0x0000);LCD_WriteReg(0x0053, 0x013F);LCD_WriteReg(0x0061, 0x0000);LCD_WriteReg(0x006A, 0x0000);LCD_WriteReg(0x0092,0x0300); LCD_WriteReg(0x0093, 0x0005);LCD_WriteReg(0x0007, 0x0100);}else if(lcddev.id==0x4531)//OK |/|/|{LCD_WriteReg(0X00,0X0001); delay_ms(10); LCD_WriteReg(0X10,0X1628); LCD_WriteReg(0X12,0X000e);//0x0006 LCD_WriteReg(0X13,0X0A39); delay_ms(10); LCD_WriteReg(0X11,0X0040); LCD_WriteReg(0X15,0X0050); delay_ms(10); LCD_WriteReg(0X12,0X001e);//16 delay_ms(10); LCD_WriteReg(0X10,0X1620); LCD_WriteReg(0X13,0X2A39); delay_ms(10); LCD_WriteReg(0X01,0X0100); LCD_WriteReg(0X02,0X0300); LCD_WriteReg(0X03,0X1038);//改变方向的 LCD_WriteReg(0X08,0X0202); LCD_WriteReg(0X0A,0X0008); LCD_WriteReg(0X30,0X0000); LCD_WriteReg(0X31,0X0402); LCD_WriteReg(0X32,0X0106); LCD_WriteReg(0X33,0X0503); LCD_WriteReg(0X34,0X0104); LCD_WriteReg(0X35,0X0301); LCD_WriteReg(0X36,0X0707); LCD_WriteReg(0X37,0X0305); LCD_WriteReg(0X38,0X0208); LCD_WriteReg(0X39,0X0F0B); LCD_WriteReg(0X41,0X0002); LCD_WriteReg(0X60,0X2700); LCD_WriteReg(0X61,0X0001); LCD_WriteReg(0X90,0X0210); LCD_WriteReg(0X92,0X010A); LCD_WriteReg(0X93,0X0004); LCD_WriteReg(0XA0,0X0100); LCD_WriteReg(0X07,0X0001); LCD_WriteReg(0X07,0X0021); LCD_WriteReg(0X07,0X0023); LCD_WriteReg(0X07,0X0033); LCD_WriteReg(0X07,0X0133); LCD_WriteReg(0XA0,0X0000); }else if(lcddev.id==0x4535){ LCD_WriteReg(0X15,0X0030); LCD_WriteReg(0X9A,0X0010); LCD_WriteReg(0X11,0X0020); LCD_WriteReg(0X10,0X3428); LCD_WriteReg(0X12,0X0002);//16 LCD_WriteReg(0X13,0X1038); delay_ms(40); LCD_WriteReg(0X12,0X0012);//16 delay_ms(40); LCD_WriteReg(0X10,0X3420); LCD_WriteReg(0X13,0X3038); delay_ms(70); LCD_WriteReg(0X30,0X0000); LCD_WriteReg(0X31,0X0402); LCD_WriteReg(0X32,0X0307); LCD_WriteReg(0X33,0X0304); LCD_WriteReg(0X34,0X0004); LCD_WriteReg(0X35,0X0401); LCD_WriteReg(0X36,0X0707); LCD_WriteReg(0X37,0X0305); LCD_WriteReg(0X38,0X0610); LCD_WriteReg(0X39,0X0610); LCD_WriteReg(0X01,0X0100); LCD_WriteReg(0X02,0X0300); LCD_WriteReg(0X03,0X1030);//改变方向的 LCD_WriteReg(0X08,0X0808); LCD_WriteReg(0X0A,0X0008); LCD_WriteReg(0X60,0X2700); LCD_WriteReg(0X61,0X0001); LCD_WriteReg(0X90,0X013E); LCD_WriteReg(0X92,0X0100); LCD_WriteReg(0X93,0X0100); LCD_WriteReg(0XA0,0X3000); LCD_WriteReg(0XA3,0X0010); LCD_WriteReg(0X07,0X0001); LCD_WriteReg(0X07,0X0021); LCD_WriteReg(0X07,0X0023); LCD_WriteReg(0X07,0X0033); LCD_WriteReg(0X07,0X0133); }else if(lcddev.id==0X1963){LCD_WR_REG(0xE2); //Set PLL with OSC = 10MHz (hardware), Multiplier N = 35, 250MHz < VCO < 800MHz = OSC*(N+1), VCO = 300MHzLCD_WR_DATA(0x1D); //参数1 LCD_WR_DATA(0x02); //参数2 Divider M = 2, PLL = 300/(M+1) = 100MHzLCD_WR_DATA(0x04); //参数3 Validate M and N values delay_us(100);LCD_WR_REG(0xE0); // Start PLL commandLCD_WR_DATA(0x01); // enable PLLdelay_ms(10);LCD_WR_REG(0xE0); // Start PLL command againLCD_WR_DATA(0x03); // now, use PLL output as system clock delay_ms(12); LCD_WR_REG(0x01); //软复位delay_ms(10);LCD_WR_REG(0xE6); //设置像素频率,33MhzLCD_WR_DATA(0x2F);LCD_WR_DATA(0xFF);LCD_WR_DATA(0xFF);LCD_WR_REG(0xB0); //设置LCD模式LCD_WR_DATA(0x20); //24位模式LCD_WR_DATA(0x00); //TFT 模式 LCD_WR_DATA((SSD_HOR_RESOLUTION-1)>>8);//设置LCD水平像素LCD_WR_DATA(SSD_HOR_RESOLUTION-1); LCD_WR_DATA((SSD_VER_RESOLUTION-1)>>8);//设置LCD垂直像素LCD_WR_DATA(SSD_VER_RESOLUTION-1); LCD_WR_DATA(0x00); //RGB序列 LCD_WR_REG(0xB4); //Set horizontal periodLCD_WR_DATA((SSD_HT-1)>>8);LCD_WR_DATA(SSD_HT-1);LCD_WR_DATA(SSD_HPS>>8);LCD_WR_DATA(SSD_HPS);LCD_WR_DATA(SSD_HOR_PULSE_WIDTH-1);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xB6); //Set vertical periodLCD_WR_DATA((SSD_VT-1)>>8);LCD_WR_DATA(SSD_VT-1);LCD_WR_DATA(SSD_VPS>>8);LCD_WR_DATA(SSD_VPS);LCD_WR_DATA(SSD_VER_FRONT_PORCH-1);LCD_WR_DATA(0x00);LCD_WR_DATA(0x00);LCD_WR_REG(0xF0); //设置SSD1963与CPU接口为16bit LCD_WR_DATA(0x03); //16-bit(565 format) data for 16bpp LCD_WR_REG(0x29); //开启显示//设置PWM输出 背光通过占空比可调 LCD_WR_REG(0xD0); //设置自动白平衡DBCLCD_WR_DATA(0x00); //disableLCD_WR_REG(0xBE); //配置PWM输出LCD_WR_DATA(0x05); //1设置PWM频率LCD_WR_DATA(0xFE); //2设置PWM占空比LCD_WR_DATA(0x01); //3设置CLCD_WR_DATA(0x00); //4设置DLCD_WR_DATA(0x00); //5设置E LCD_WR_DATA(0x00); //6设置F LCD_WR_REG(0xB8); //设置GPIO配置LCD_WR_DATA(0x03); //2个IO口设置成输出LCD_WR_DATA(0x01); //GPIO使用正常的IO功能 LCD_WR_REG(0xBA);LCD_WR_DATA(0X01); //GPIO[1:0]=01,控制LCD方向LCD_SSD_BackLightSet(100);//背光设置为最亮} LCD_Display_Dir(0); //默认为竖屏LCD_LED=1; //点亮背光LCD_Clear(WHITE);
}
//清屏函数
//color:要清屏的填充色
void LCD_Clear(u16 color)
{u32 index=0; u32 totalpoint=lcddev.width;totalpoint*=lcddev.height; //得到总点数if((lcddev.id==0X6804)&&(lcddev.dir==1))//6804横屏的时候特殊处理 { lcddev.dir=0; lcddev.setxcmd=0X2A;lcddev.setycmd=0X2B; LCD_SetCursor(0x00,0x0000); //设置光标位置 lcddev.dir=1; lcddev.setxcmd=0X2B;lcddev.setycmd=0X2A; }else LCD_SetCursor(0x00,0x0000); //设置光标位置 LCD_WriteRAM_Prepare(); //开始写入GRAM for(index=0;index<totalpoint;index++){LCD->LCD_RAM=color; }
}
//在指定区域内填充单个颜色
//(sx,sy),(ex,ey):填充矩形对角坐标,区域大小为:(ex-sx+1)*(ey-sy+1)
//color:要填充的颜色
void LCD_Fill(u16 sx,u16 sy,u16 ex,u16 ey,u16 color)
{ u16 i,j;u16 xlen=0;u16 temp;if((lcddev.id==0X6804)&&(lcddev.dir==1)) //6804横屏的时候特殊处理 {temp=sx;sx=sy;sy=lcddev.width-ex-1; ex=ey;ey=lcddev.width-temp-1;lcddev.dir=0; lcddev.setxcmd=0X2A;lcddev.setycmd=0X2B; LCD_Fill(sx,sy,ex,ey,color); lcddev.dir=1; lcddev.setxcmd=0X2B;lcddev.setycmd=0X2A; }else{xlen=ex-sx+1; for(i=sy;i<=ey;i++){LCD_SetCursor(sx,i); //设置光标位置 LCD_WriteRAM_Prepare(); //开始写入GRAM for(j=0;j<xlen;j++)LCD->LCD_RAM=color; //显示颜色 }}
}
//在指定区域内填充指定颜色块
//(sx,sy),(ex,ey):填充矩形对角坐标,区域大小为:(ex-sx+1)*(ey-sy+1)
//color:要填充的颜色
void LCD_Color_Fill(u16 sx,u16 sy,u16 ex,u16 ey,u16 *color)
{ u16 height,width;u16 i,j;width=ex-sx+1; //得到填充的宽度height=ey-sy+1; //高度for(i=0;i<height;i++){LCD_SetCursor(sx,sy+i); //设置光标位置 LCD_WriteRAM_Prepare(); //开始写入GRAMfor(j=0;j<width;j++)LCD->LCD_RAM=color[i*width+j];//写入数据 }
}
//画线
//x1,y1:起点坐标
//x2,y2:终点坐标
void LCD_DrawLine(u16 x1, u16 y1, u16 x2, u16 y2)
{u16 t; int xerr=0,yerr=0,delta_x,delta_y,distance; int incx,incy,uRow,uCol; delta_x=x2-x1; //计算坐标增量 delta_y=y2-y1; uRow=x1; uCol=y1; if(delta_x>0)incx=1; //设置单步方向 else if(delta_x==0)incx=0;//垂直线 else {incx=-1;delta_x=-delta_x;} if(delta_y>0)incy=1; else if(delta_y==0)incy=0;//水平线 else{incy=-1;delta_y=-delta_y;} if( delta_x>delta_y)distance=delta_x; //选取基本增量坐标轴 else distance=delta_y; for(t=0;t<=distance+1;t++ )//画线输出 { LCD_DrawPoint(uRow,uCol);//画点 xerr+=delta_x ; yerr+=delta_y ; if(xerr>distance) { xerr-=distance; uRow+=incx; } if(yerr>distance) { yerr-=distance; uCol+=incy; } }
}
//画矩形
//(x1,y1),(x2,y2):矩形的对角坐标
void LCD_DrawRectangle(u16 x1, u16 y1, u16 x2, u16 y2)
{LCD_DrawLine(x1,y1,x2,y1);LCD_DrawLine(x1,y1,x1,y2);LCD_DrawLine(x1,y2,x2,y2);LCD_DrawLine(x2,y1,x2,y2);
}
//在指定位置画一个指定大小的圆
//(x,y):中心点
//r :半径
void LCD_Draw_Circle(u16 x0,u16 y0,u8 r)
{int a,b;int di;a=0;b=r; di=3-(r<<1); //判断下个点位置的标志while(a<=b){LCD_DrawPoint(x0+a,y0-b); //5LCD_DrawPoint(x0+b,y0-a); //0 LCD_DrawPoint(x0+b,y0+a); //4 LCD_DrawPoint(x0+a,y0+b); //6 LCD_DrawPoint(x0-a,y0+b); //1 LCD_DrawPoint(x0-b,y0+a); LCD_DrawPoint(x0-a,y0-b); //2 LCD_DrawPoint(x0-b,y0-a); //7 a++;//使用Bresenham算法画圆 if(di<0)di +=4*a+6; else{di+=10+4*(a-b); b--;} }
} 在指定位置显示一个字符
x,y:起始坐标
num:要显示的字符:" "--->"~"
size:字体大小 12/16/24
mode:叠加方式(1)还是非叠加方式(0)
//void LCD_ShowChar(u16 x,u16 y,u8 num,u8 size,u8 mode)
//{
// u8 temp,t1,t;
// u16 y0=y;
// u8 csize=(size/8+((size%8)?1:0))*(size/2); //得到字体一个字符对应点阵集所占的字节数
// num=num-' ';//得到偏移后的值（ASCII字库是从空格开始取模，所以-' '就是对应字符的字库）
// for(t=0;t<csize;t++)
// {
// if(size==12)temp=asc2_1206[num][t]; //调用1206字体
// else if(size==16)temp=asc2_1608[num][t]; //调用1608字体
// else if(size==24)temp=asc2_2412[num][t]; //调用2412字体
// else if(size==32)temp=asc3232[num][t]; //32
// else if(size==64)temp=asc6464[num][t]; //64
// else return; //没有的字库
// for(t1=0;t1<8;t1++)
// {
// if(temp&0x80)LCD_Fast_DrawPoint(x,y,POINT_COLOR);
// else if(mode==0)LCD_Fast_DrawPoint(x,y,BACK_COLOR);
// temp<<=1;
// y++;
// if(y>=lcddev.height)return; //超区域了
// if((y-y0)==size)
// {
// y=y0;
// x++;
// if(x>=lcddev.width)return; //超区域了
// break;
// }
// }
// }
//} //新的LCD_ShowChar,新增32,64ASC字库，可移植非8整数倍字号字库
void LCD_ShowChar(u16 x,u16 y,u8 num,u8 size,u8 mode);//m^n函数
//返回值:m^n次方.
u32 LCD_Pow(u8 m,u8 n)
{u32 result=1; while(n--)result*=m; return result;
}
//显示数字,高位为0,则不显示
//x,y :起点坐标
//len :数字的位数
//size:字体大小
//color:颜色
//num:数值(0~4294967295);
void LCD_ShowNum(u16 x,u16 y,u32 num,u8 len,u8 size)
{ u8 t,temp;u8 enshow=0; for(t=0;t<len;t++){temp=(num/LCD_Pow(10,len-t-1))%10;if(enshow==0&&t<(len-1)){if(temp==0){LCD_ShowChar(x+(size/2)*t,y,' ',size,0);continue;}else enshow=1; }LCD_ShowChar(x+(size/2)*t,y,temp+'0',size,0); }
}
//显示数字,高位为0,还是显示
//x,y:起点坐标
//num:数值(0~999999999);
//len:长度(即要显示的位数)
//size:字体大小
//mode:
//[7]:0,不填充;1,填充0.
//[6:1]:保留
//[0]:0,非叠加显示;1,叠加显示.
void LCD_ShowxNum(u16 x,u16 y,u32 num,u8 len,u8 size,u8 mode)
{ u8 t,temp;u8 enshow=0; for(t=0;t<len;t++){temp=(num/LCD_Pow(10,len-t-1))%10;if(enshow==0&&t<(len-1)){if(temp==0){if(mode&0X80)LCD_ShowChar(x+(size/2)*t,y,'0',size,mode&0X01); else LCD_ShowChar(x+(size/2)*t,y,' ',size,mode&0X01); continue;}else enshow=1; }LCD_ShowChar(x+(size/2)*t,y,temp+'0',size,mode&0X01); }
}
//显示字符串
//x,y:起点坐标
//width,height:区域大小
//size:字体大小
//*p:字符串起始地址
void LCD_ShowString(u16 x,u16 y,u16 width,u16 height,u8 size,u8 *p)
{ u8 x0=x;width+=x;height+=y;while((*p<='~')&&(*p>=' '))//判断是不是非法字符!{ if(x>=width){x=x0;y+=size;}if(y>=height)break;//退出LCD_ShowChar(x,y,*p,size,0);x+=size/2;p++;}
}u8 Disguise_ChineseSize(u8 size,u8 num,u32 t)
{u8 tempx;if(size==8) tempx= chinese_one_88[num][t];if(size==9) tempx= chinese_one_99[num][t];if(size==10) tempx= chinese_one_1010[num][t];if(size==11) tempx= chinese_one_1111[num][t];if(size==12) tempx= chinese_one_1212[num][t];if(size==13) tempx= chinese_one_1313[num][t];if(size==14) tempx= chinese_one_1414[num][t];if(size==15) tempx= chinese_one_1515[num][t];if(size==16) tempx= chinese_one_1616[num][t];if(size==17) tempx= chinese_one_1717[num][t];if(size==18) tempx= chinese_one_1818[num][t];if(size==19) tempx= chinese_one_1919[num][t];if(size==20) tempx= chinese_one_2020[num][t];if(size==21) tempx= chinese_one_2121[num][t];if(size==22) tempx= chinese_one_2222[num][t];if(size==23) tempx= chinese_one_2323[num][t];if(size==24) tempx= chinese_one_2424[num][t];if(size==25) tempx= chinese_one_2525[num][t];if(size==26) tempx= chinese_one_2626[num][t];if(size==27) tempx= chinese_one_2727[num][t];if(size==28) tempx= chinese_one_2828[num][t];if(size==29) tempx= chinese_one_2929[num][t];if(size==30) tempx= chinese_one_3030[num][t];if(size==31) tempx= chinese_one_3131[num][t];if(size==32) tempx= chinese_one_3232[num][t];if(size==64) tempx= chinese_one_6464[num][t];return tempx;
}u8 Disguise_CharSize(u8 size,u8 num,u32 t)
{u8 tempx;if(size==12)tempx=asc2_1206[num][t]; //调用1206字体if(size==16)tempx=asc2_1608[num][t]; //调用1608字体if(size==24)tempx=asc2_2412[num][t]; //调用2412字体if(size==32)tempx=asc3232[num][t]; //32if(size==64)tempx=asc6464[num][t]; //64return tempx;
}void LCD_ShowOneChinese(u8 x, u8 y, u8 num, u8 size, u8 mode)
{u8 temp,t1;u32 t;u8 y0 = y;u8 i;u16 csize;for(i=8;i<=range;i+=8){if(size>i&&size<i+8){csize = ((size + 7) / 8) * size; for(t = 0; t < csize; t++){ temp = Disguise_ChineseSize(size,num,t);u8 valid_bits = (t % ((i/8)+1) == (i/8)) ? (size%8) : 8; for(t1 = 0; t1 < valid_bits; t1++){if(temp & (0x80 >> t1)) // 从最高位开始逐位检测（右移t1位）LCD_Fast_DrawPoint(x, y, POINT_COLOR); // 前景色else LCD_Fast_DrawPoint(x, y, BACK_COLOR); // 背景色y++;if(y>=lcddev.height)return; //超区域了if((y - y0) == size) {y = y0;x++;if(x>=lcddev.width)return; //超区域了break;}} } }else if(size==i){csize = (size/8) * size; for(t=0;t<csize;t++){ temp = Disguise_ChineseSize(size,num,t); for(t1=0;t1<8;t1++){if(temp&0x80) LCD_Fast_DrawPoint(x,y,POINT_COLOR);else LCD_Fast_DrawPoint(x,y,BACK_COLOR);temp<<=1;y++;if(y>=lcddev.height)return; //超区域了if((y-y0)==size){y=y0;x++;if(x>=lcddev.width)return; //超区域了break;}} }}}}//number为一共有几个汉字
//form表示汉字是横排还是竖排，0为竖排1为横排，2为number表示序号用于显示font.h字库中汉字
void LCD_ShowChinese(u8 x, u8 y, u8 number , u8 size,u8 mode,u8 form)
{u8 i=0;u8 temp=x;u8 temp1=y;for(i=0;i<=number-1;i++){x=temp;y=temp1;if(form==1){x += size*i;LCD_ShowOneChinese(x,y,i,size,mode);}else if(form==0){y += size*i;LCD_ShowOneChinese(x,y,i,size,mode);}else{LCD_ShowOneChinese(x,y,number-1,size,mode);//此时number表示序号，1为起始序号}}}在指定位置显示一个字符
x,y:起始坐标
num:要显示的字符:" "--->"~"
size:字体大小 12/16/24
mode:叠加方式(1)还是非叠加方式(0)
void LCD_ShowChar(u16 x,u16 y,u8 num,u8 size,u8 mode)
{ u8 temp,t1;u32 t;u8 y0 = y;u8 i;u16 csize;num=num-' ';//得到偏移后的值（ASCII字库是从空格开始取模，所以-' '就是对应字符的字库）for(i=8;i<=range;i+=8){if(size>i&&size<i+8){csize = ((size + 7) / 8) * size; for(t = 0; t < csize; t++){ temp = Disguise_CharSize(size,num,t);u8 valid_bits = (t % ((i/8)+1) == (i/8)) ? (size%8) : 8; for(t1 = 0; t1 < valid_bits; t1++){if(temp & (0x80 >> t1)) // 从最高位开始逐位检测（右移t1位）LCD_Fast_DrawPoint(x, y, POINT_COLOR); // 前景色else if(mode==0)LCD_Fast_DrawPoint(x, y, BACK_COLOR); // 背景色y++;if(y>=lcddev.height)return; //超区域了if((y - y0) == size) {y = y0;x++;if(x>=lcddev.width)return; //超区域了break;}} } }else if(size==i){csize=(size/8+((size%8)?1:0))*(size/2);for(t=0;t<csize;t++){ temp = Disguise_CharSize(size,num,t); for(t1=0;t1<8;t1++){if(temp&0x80) LCD_Fast_DrawPoint(x,y,POINT_COLOR);else if(mode==0)LCD_Fast_DrawPoint(x,y,BACK_COLOR);temp<<=1;y++;if(y>=lcddev.height)return; //超区域了if((y-y0)==size){y=y0;x++;if(x>=lcddev.width)return; //超区域了break;}} }}}
}lcd.h
#ifndef __LCD_H
#define __LCD_H
#include "sys.h"
#include "stdlib.h"
//
//STM32F103ZE核心板//2.4寸/2.8寸/3.5寸/4.3寸/7寸 TFT液晶驱动
//支持驱动IC型号包括:ILI9341/ILI9325/RM68042/RM68021/ILI9320/ILI9328/LGDP4531/LGDP4535/
// SPFD5408/1505/B505/C505/NT35310/NT35510/SSD1963等 //********************************************************************************// //LCD重要参数集
typedef struct
{ u16 width; //LCD 宽度u16 height; //LCD 高度u16 id; //LCD IDu8 dir; //横屏还是竖屏控制：0，竖屏；1，横屏。 u16 wramcmd; //开始写gram指令u16 setxcmd; //设置x坐标指令u16 setycmd; //设置y坐标指令
}_lcd_dev; //LCD参数
extern _lcd_dev lcddev; //管理LCD重要参数
//LCD的画笔颜色和背景色
extern u16 POINT_COLOR;//默认红色
extern u16 BACK_COLOR; //背景颜色.默认为白色//
//-----------------LCD端口定义----------------
#define LCD_LED PBout(0) //LCD背光 PB0
//LCD地址结构体
typedef struct
{vu16 LCD_REG;vu16 LCD_RAM;
} LCD_TypeDef;
//使用NOR/SRAM的 Bank1.sector4,地址位HADDR[27,26]=11 A10作为数据命令区分线
//注意设置时STM32内部会右移一位对其!
#define LCD_BASE ((u32)(0x6C000000 | 0x000007FE))
#define LCD ((LCD_TypeDef *) LCD_BASE)
////扫描方向定义
#define L2R_U2D 0 //从左到右,从上到下
#define L2R_D2U 1 //从左到右,从下到上
#define R2L_U2D 2 //从右到左,从上到下
#define R2L_D2U 3 //从右到左,从下到上#define U2D_L2R 4 //从上到下,从左到右
#define U2D_R2L 5 //从上到下,从右到左
#define D2U_L2R 6 //从下到上,从左到右
#define D2U_R2L 7 //从下到上,从右到左 #define DFT_SCAN_DIR L2R_U2D //默认的扫描方向//画笔颜色
#define WHITE 0xFFFF
#define BLACK 0x0000
#define BLUE 0x001F
#define BRED 0XF81F
#define GRED 0XFFE0
#define GBLUE 0X07FF
#define RED 0xF800
#define MAGENTA 0xF81F
#define GREEN 0x07E0
#define CYAN 0x7FFF
#define YELLOW 0xFFE0
#define BROWN 0XBC40 //棕色
#define BRRED 0XFC07 //棕红色
#define GRAY 0X8430 //灰色
//GUI颜色#define DARKBLUE 0X01CF //深蓝色
#define LIGHTBLUE 0X7D7C //浅蓝色
#define GRAYBLUE 0X5458 //灰蓝色
//以上三色为PANEL的颜色 #define LIGHTGREEN 0X841F //浅绿色
//#define LIGHTGRAY 0XEF5B //浅灰色(PANNEL)
#define LGRAY 0XC618 //浅灰色(PANNEL),窗体背景色#define LGRAYBLUE 0XA651 //浅灰蓝色(中间层颜色)
#define LBBLUE 0X2B12 //浅棕蓝色(选择条目的反色)void LCD_Init(void); //初始化
void LCD_DisplayOn(void); //开显示
void LCD_DisplayOff(void); //关显示
void LCD_Clear(u16 Color); //清屏
void LCD_SetCursor(u16 Xpos, u16 Ypos); //设置光标
void LCD_DrawPoint(u16 x,u16 y); //画点
void LCD_Fast_DrawPoint(u16 x,u16 y,u16 color); //快速画点
u16 LCD_ReadPoint(u16 x,u16 y); //读点
void LCD_Draw_Circle(u16 x0,u16 y0,u8 r); //画圆
void LCD_DrawLine(u16 x1, u16 y1, u16 x2, u16 y2); //画线
void LCD_DrawRectangle(u16 x1, u16 y1, u16 x2, u16 y2); //画矩形
void LCD_Fill(u16 sx,u16 sy,u16 ex,u16 ey,u16 color); //填充单色
void LCD_Color_Fill(u16 sx,u16 sy,u16 ex,u16 ey,u16 *color); //填充指定颜色
void LCD_ShowChar(u16 x,u16 y,u8 num,u8 size,u8 mode); //显示一个字符
void LCD_ShowNum(u16 x,u16 y,u32 num,u8 len,u8 size); //显示一个数字
void LCD_ShowxNum(u16 x,u16 y,u32 num,u8 len,u8 size,u8 mode); //显示 数字
void LCD_ShowString(u16 x,u16 y,u16 width,u16 height,u8 size,u8 *p); //显示一个字符串,12/16/24/32/64字体
void LCD_ShowChinese(u8 x, u8 y, u8 number , u8 size,u8 mode,u8 form); //显示一个8~64（可自行修改更大范围）字符或汉字，需取字模后移入font.hvoid LCD_WriteReg(u16 LCD_Reg, u16 LCD_RegValue);
u16 LCD_ReadReg(u16 LCD_Reg);
void LCD_WriteRAM_Prepare(void);
void LCD_WriteRAM(u16 RGB_Code);
void LCD_SSD_BackLightSet(u8 pwm); //SSD1963 背光控制
void LCD_Scan_Dir(u8 dir); //设置屏扫描方向
void LCD_Display_Dir(u8 dir); //设置屏幕显示方向
void LCD_Set_Window(u16 sx,u16 sy,u16 width,u16 height); //设置窗口
//LCD分辨率设置
#define SSD_HOR_RESOLUTION 800 //LCD水平分辨率
#define SSD_VER_RESOLUTION 480 //LCD垂直分辨率
//LCD驱动参数设置
#define SSD_HOR_PULSE_WIDTH 1 //水平脉宽
#define SSD_HOR_BACK_PORCH 46 //水平前廊
#define SSD_HOR_FRONT_PORCH 210 //水平后廊#define SSD_VER_PULSE_WIDTH 1 //垂直脉宽
#define SSD_VER_BACK_PORCH 23 //垂直前廊
#define SSD_VER_FRONT_PORCH 22 //垂直前廊
//如下几个参数，自动计算
#define SSD_HT (SSD_HOR_RESOLUTION+SSD_HOR_BACK_PORCH+SSD_HOR_FRONT_PORCH)
#define SSD_HPS (SSD_HOR_BACK_PORCH)
#define SSD_VT (SSD_VER_RESOLUTION+SSD_VER_BACK_PORCH+SSD_VER_FRONT_PORCH)
#define SSD_VPS (SSD_VER_BACK_PORCH)#endif font.h
const u16 chinese_one_1616[][32]={
0x00,0x08,0x00,0x08,0x1F,0xC8,0x92,0x48,0x52,0x48,0x32,0x48,0x12,0x48,0x1F,0xFF,0x12,0x48,0x32,0x48,0x52,0x48,0x92,0x48,0x1F,0xC8,0x00,0x08,0x00,0x08,0x00,0x00,/*"单",0*/0x00,0x00,0x00,0x01,0x00,0x06,0x7F,0xF8,0x04,0x40,0x04,0x40,0x04,0x40,0x04,0x40,0x04,0x40,0xFC,0x40,0x04,0x7F,0x04,0x00,0x04,0x00,0x04,0x00,0x00,0x00,0x00,0x00,/*"片",1*/0x08,0x20,0x08,0xC0,0x0B,0x00,0xFF,0xFF,0x09,0x00,0x08,0xC1,0x00,0x06,0x7F,0xF8,0x40,0x00,0x40,0x00,0x40,0x00,0x7F,0xFC,0x00,0x02,0x00,0x02,0x00,0x1E,0x00,0x00,/*"机",2*/
};const u16 chinese_one_88[][8];
const u16 chinese_one_99[][16];
const u16 chinese_one_1010[][20];
const u16 chinese_one_1111[][20];
const u16 chinese_one_1212[][24];
const u16 chinese_one_1313[][24];
const u16 chinese_one_1414[][24];
const u16 chinese_one_1515[][28];
//const u16 chinese_one_1616[][32];
const u16 chinese_one_1717[][48];
const u16 chinese_one_1818[][54];
const u16 chinese_one_1919[][54];
const u16 chinese_one_2020[][60];
const u16 chinese_one_2121[][60];
const u16 chinese_one_2222[][66];
const u16 chinese_one_2323[][66];
const u16 chinese_one_2424[][72];
const u16 chinese_one_2525[][96];
const u16 chinese_one_2626[][104];
const u16 chinese_one_2727[][104];
const u16 chinese_one_2828[][112];
const u16 chinese_one_2929[][112];
const u16 chinese_one_3030[][120];
const u16 chinese_one_3131[][120];
const u16 chinese_one_3232[][128];
//点阵为32*32
const u32 chinese_one_6464[][512];//ASCLL字库可自己添加
——Spring MVC)
